Excavator hydraulic milling cutter EK 100

Overview
The EK 100 chain cutter for medium excavators uses KEMROC’s patented chain cutting technology to provide continuous, non-percussive cutting for precise trench geometry and low vibration. Built for excavators in the 18–30 t class, the EK 100 handles soil, concrete and medium to hard rock up to 80 MPa UCS, enabling consistent production in demanding ground conditions for utilities, pipeline and heavy civil works.

Key benefits

• Cutting depth up to 1,970 mm
• Available cutting widths: 600, 700 or 800 mm
• Continuous chain cutting for clean trench walls and reduced vibration
• Capable of working in formations up to 80 MPa UCS
• Stable machine operation and predictable production rates

Technical data (summary)
Recommended excavator weight: 18 – 30 t
Rated power: 100 kW
Drum cutter length (A): 1970 mm
Cutting width (B): 600 | 700 | 800 mm
Cutter drum diameter (C): 800 mm
Recommended rpm: 65 rpm
Recommended oil flow: 200 l/min
Max. oil flow: 260 l/min
Max. operating pressure: 400 bar
Torque at 380 bar: 15,700 Nm
Cutting force at 380 bar: 39 kN
Max. rock compressive strength: 80 MPa
Weight (depending on width/configuration): 2,450 | 2,510 | 2,620 kg
Pick box type: PH 32 HD
Number of picks in cutter drums: 28 | 40 | 48 pcs (depending on width)
Number of picks in the cutter chain: 54 pcs
Standard pick: 17/75/70/30 Q
Standard hole pattern: LB30
Compatible rotation unit (KRM): KRM50

Applications

• Deep infrastructure and utility trenching (large-diameter pipelines, high-capacity cable routes)
• Road and civil engineering: removal of concrete road structures and compacted layers
• Selective excavation in rock and reinforced concrete where precise removal is required
• Trenching in medium to hard rock types (limestone, sandstone, carbonate) up to 80 MPa UCS

Technical specifications

• Recommended excavator weight: 18 – 30 t
• Rated power: 100 kW
• Drum cutter length (A): 1970 mm
• Cutting width (B): 600 | 700 | 800 mm
• Cutter drum diameter (C): 800 mm
• Recommended rpm: 65 rpm
• Recommended oil flow: 200 l/min
• Maximum oil flow: 260 l/min
• Maximum operating pressure: 400 bar
• Torque at 380 bar: 15,700 Nm
• Cutting force at 380 bar: 39 kN
• Maximum rock compressive strength: 80 MPa
• Weight: 2,450 | 2,510 | 2,620 kg
• Pick box type: PH 32 HD
• Number of picks in cutter drums: 28 | 40 | 48 pcs
• Number of picks in the cutter chain: 54 pcs
• Standard pick: 17/75/70/30 Q
• Standard hole pattern: LB30
• Compatible rotation unit: KRM50
