Hydraulic compensator
Generally mounted inside hydraulic tanks and operating with no energy source, these products compensate the variations in volume of oil or any other fluid caused by changes in temperature or volume, whilst avoiding all risk of accident for the equipment.
PRONAL compensators also ensure that tanks are completely leakproof and protect any hydraulic fluids from external pollution by means of a totally flexible membrane which isolates them from the ambient environment. They can also act as hydraulic dampers.
Advantages :
- suitable for all types of hydraulic circuit,
- prevents air emulsifying in the oil,
- leakproof hydraulic circuits,
- pressurisation of the tanks,
- maintenance-free and very long service life
A highly diversified range of products :
- capacities vary between 0.1 and 10,000 litres,
- standard and customized range with a wide choice of solutions offering hydraulic protection.
|
|
| ... products without technical information |
| |
WL15 in-tank filter meets the HF4 automotive standard. The E4051 service elements interchange with Schroeder K series and Zinga RE-409 series.
An optional weld ring provides an easy solution to insure a positive seal between housing and reservoir. The quick disconnect cover allows for easy and
efficient element change-outs. An optional secondary inlet port offers the use of a second return line. An optional weld ring provides an easy solution to
insure a positive seal between housing and reservoir. Five standard grades of media are offered down to 4.0μ(c).
Western Filter elements are compatible with petroleum oils, water glycol, oil/water, HWCF and synthetic fluids.
|
|
|
The WT, WL and WR Intank series is designed for return line applications. These filters operate with pressures up to 200 psi and fows to 320 gpm. The WL16 and WL18 series offers additional design flexibility with the optional anti-drain valve for side mounting the filter to the reservoir. Filtration flow on the WR series is from inside to outside of the filter element to capture contamination inside the element. The WR11 series is designed to meet flow requirements up to 40 gpm in a light weight compact design.
|
|
|
|
