The concept of the DSA100 encompasses everything from fully manual to fully automated contact angle measurement. Due to its modular concept, virtually any level of automation can be achieved - even with post-sales additions.
Flexible sample size, flexible measuring technique - with its double modularity concept KRÜSS GmbH has revolutionized contact angle measuring technology. No matter what measuring problem you have to face - the DSA100 will grow to meet your requirements. A total of more than 30000 different combinations is available from the DSA100 building block system; any necessary or required degree of automation can be realized in next to no time.
|
|
EasyDrop Standard for PC operation and EasyDrop USB for working with a notebook: with these two instruments in the new KRÜSS product range measuring contact angles and surface free energy is as quick and simple as rarely before. The duo offers everything required for both routine lab work and on-site measurements. Quality managers gain quick access to reliable results. Scientists use the sophisticated analytical tools for research at a high level. The chiefly manual components ensure that EasyDrop remains favorably priced despite its high performance level.
- Contact angles easy and fast
- Fast and precise dosing and sample positioning
- Budget-friendly thanks to manual operation
- Several drop shape analysis methods for big and small angles
- Surface energy by all established methods
- Surface tension with the pendant drop method
- Comfortable evaluation and data management
|
|
|
|
|
|
Mobile contact angle measurement on samples of virtually any size
In the field of quality assurance the demand is increasing for flexible instruments that can be used in the field and which allow tests on materials while processes are being carried out. The MobileDrop from KRÜSS closes this gap in the contact angle measurement field.
MobileDrop is operated with only one hand and permits measurements to be made on surfaces of virtually any size. Despite its small space requirements, a prism optics system ensures a sharp image of the drop contour. Drop deposition with different liquids allows the surface free energy and its polar and dispersive fractions to be determined in a short time. All components are contained in an ergonomic housing together with a USB camera.
The video image is transferred to a notebook which does the mental work: analysis of the drop shape and calculation of contact angles and surface energies with the software DSA2. An extensive substance database and comfortable tools for data administration are included.
|
|
|
TAB2 model is a measuring system equipped with a camera to be mounted on board machine, capable of measuring both spring length and diameters coil by coil. Besides, the system interacts with the manufacturing machine to correct both length and diameters. It is equipped with a PC based on Windows XP and Excel. All the results are stored, thus allowing to obtain statistics and to print customizable certificates.
|
|
|
|
|
|
Optigo RE is a versatile 3D optical measurement system based on the unique white light stereo vision technology by CogniTens. Designed to withstand the harsh conditions of the engineering and manufacturing environments, the system demonstrates low sensitivity to structural vibrations. Its performance is not affected by changing industrial illumination & ambient lighting and does not require pretreatment of measured objects in most dimensional measurement applications.
Optigo RE provides manufacturing and quality engineers a comprehensive metrology feedback on:
- full 3D surfaces & geometries
- common manufacturing features
- various edge types
- other dimensions of interest
Integrated with the latest version 3.7 of its powerful software, Optigo RE streamlines the measurement process making it the fastest solution available. Using new processing methods and multi core computing technology Optigo RE demonstrates performance acceleration throughout all processes and capable to support real-time quality iterations or detailed studies.
The latest Optigo RE model incorporates new optical 3D textured light based measurement technology and software additional to the stereo vision technology. Optigo RE serves primarily as:
- A reliable shop floor measurement system for dimensional evaluation and qualification
- A 3D digitization system for closing the loop with product design & supporting advanced engineering studies.
Optigo RE allows generating high quality STL and point cloud outputs with emphasis on surface smoothness, tight geometry tracking, crisp closed features, etc.
|
|
|
|
|
|
Optigo
A portable and comprehensive dimensional measurement platform that supports critical product development, production engineering, and manufacturing processes for the automotive and other industries
Optigo is a portable, high-performance dimensional measurement platform used in engineering, production, and assembly processes on the shop floor. Compact for easy handling and access, Optigo’s design blends ruggedness with precise instrumentation. Its performance is not affected by vibrations, industrial lighting, or temperature changes. CogniTens’ patented technology guarantees fast throughput and superior accuracy. From prototyping to ramp up and launch, Optigo delivers a comprehensive solution for the full range of automotive metrology challenges.
Comprehensive Solution
Optigo was specifically designed for flexible operation in demanding engineering and manufacturing environments. Optigo is an industry proven robust platform which is accompanied by embedded software used for:
Planning and defining measurement programs
Guiding and executing the measurement programs using the Optigo
Real time analysis of measurement results
Generating and distributing standard and customized reports
Supporting reverse engineering activities
Optigo is especially suited for numerous applications in the automotive and aerospace industries such as:
Prototype Development & Quality Assurance
Die & Mold development and tryout
Hydroformed & Stamped parts validation
Assembly process development
Manufacturing root cause analysis during production launch
Intelligent Reverse Engineering
|
|
ROMER SIGMA - For a Precise and Simple Measurements
The SIGMA Arm completely matches all your metrology needs thanks to exclusive concept “MODULARM”: 10 lengths of arms available for measurement without limit. With the longest arm length available on the market, the SIGMA series exceeds the capabilities of other measurement equipment.
The SIGMA Arm offers total flexibility because of the wireless communication and is one of the lightest arms in its class. The SIGMA series provides total compatibility with all ROMER accessories and equipment (sensors with and without contact, laser digitalization sensors, numerical rails, VPS…).
Choose ROMER, the creator of the 3D portable measuring arms, and profit from a fast, intuitive measurement without constraints.
|
|
Articulated SIGMA Arms
The SIGMA arm completely matches all your metrology needs thanks to exclusive concept "MODULARM": 10 lengths of arms available for measurement without limit. With the longest arm length available on the market, the SIGMA series exceeds the capabilities of other measurement equipment The SIGMA arm offers total flexibility thanks to the security of the wireless communication and is one of the lightest arms in its class.
|
|
|
|
|
|
SOLO System
A complete and truly portable measurement system consisting of a single sensor, a probing and a computer system.
The industry-proven solution has been fused with new technology and design to produce the 3rd generation Metronor portable CMM system. More accurate, more portable and even easier and faster to use than ever. New technology and innovations has allowed us to bring the price down to make it the most cost-effective portable CMM available in the market today.
Whether you are building the best possible aircraft, the highest quality car bodies or a new turbine blade you need exact measurements. Metronor has delivered portable CMM systems to the most demanding industries for well over a decade and proven that our systems will deliver excellent accuracy and functionality.
* Complete and truly portable: One box, 24kg, for complete system including computer and tripod.
* Extended probing capabilities including hidden features (450mm plus probe length).
* Operator friendly: Probing without beams, wires or arms.
* Fast and easy set-up and use.
* No warm-up, initialization or leap-frogging.
* No moving parts eliminate re-calibration.
* Can be upgraded to DUO and DUET system.
* Price/performance winner.
|
|
Ruler E - Gigabit 3D for Tough Environments!
A complete new generation of Ruler is here - more than four times faster and with three times higher resolution than the previous generation. Now with ultra fast Gigabit Ethernet interface!
Ruler E is the solution for demanding 3D applications in any production line. It is designed to measure anything from logs in a sawmill to cars in the automotive Industry. Ruler E is intended for tough environment with a shield level of IP65.
Ruler E contains a laser and Image sensor assembled in fixed positions. It is calibrated before delivery to give you high quality 3D data. This in combination with .Net assembly technology gives you short development time and cost effective solutions.
|
|
|
|
|
|
Traditional angular contact ball bearing measuring devices still use manual or semi-manual machines: a low degree of precision is obtained and the process time is long. The Bussi contact angle measuring machine is extremely precise, reliable, fully automatic and fast. It combines electronics with top-level engineering and pneumatics. It features:
Data setting: a computer stores the bearing data it is necessary to measure and is input just once. Every time there is a type changeover, only the bearing code needs to be recalled, thereby avoiding error and time wasting. Storage capacity: 500 types of bearing.
Automatic measurement: it makes two checks simultaneously, the contact angle measure and that all the balls are present. Field of measurement: 0° to 89.9°
Precision and repeatability: precise to ± 0.2 ° with high measurement repeatability. This performance can depend on the level of precision achieved when the bearing is constructed.
Measurement speed: the process is extremely quick, between 14 and 17 sec, with a capacity of up to 257 pieces/hr. Maximum type changeover: < 4 min
Optional automation for lines
|
|
|
|
|
|
The FARO Laser ScanArm® offers numerous new and improved features and several advantages in conjunction with the new FaroArm® Quantum - making it unique on the market for measuring machines.
The FARO Laser ScanArm enables users to inspect parts in detail by capturing huge point-cloud data. Its open architecture enables the user to employ Geomagic, Polyworks, RapidForm and many other third-party software programs.
In conjunction with the right software, the FARO Laser ScanArm tackles all measurement tasks such as inspection, point cloud-to-CAD comparison, rapid prototyping, reverse engineering, and 3D modeling. Its main benefits are the exact scanning of reflective and dark objects - the biggest challenge for all scanning systems.
The FARO Laser ScanArm is compatible with the FaroArm Quantum, Platinum, and Fusion.
Advantages of the FARO Laser ScanArm:
» Up to 30% more accurate: Laser Line Probe up to 30% more accurate than previous model
» Improved surface scanning: Higher performance when scanning dark or reflecting surfaces
» Smaller & lighter: Improved ergonomics through 30% weight reduction compared to previous model
» Faster warm-up: 50% faster warm-up time compared to previous models
» Integrated 7th axis - Higher flexibility: No external electronics and fixtures
» Ergonomic handle: Easy to handle
» Cable-free scanning: The Laser Line Probe is compatible with FaroArm's Quantum Bluetooth® technology
For more information visit: www.laserscanarm.faro.com
|
|
|
|
|
|
FARO Gage: The "All-in-One" Machine Shop Solution
The FARO Gage and Gage-PLUS are the industry's first line of personal Coordinate Measuring Machines (CMMs). With their 1.2m (48") working volume, they are the "mount-it-to-where-you-make-it", truly portable, cost-effective, 3-Dimensional, minimal-training gages for machinists. The FARO Gage line replaces all conventional measuring devices. Save time and money by replacing your cluttered inspection area with the one tool that can do it all.
Bringing new power to in-process inspection and CAD-to-part verification, the PowerGAGE includes a high-powered, easy-to-use programmer module, no-train "player" module, and extremely accurate 4-foot measurement arm. Program it once and you're done, even directly use CAD data for nominal. It was designed by and for machinists to speed through measurement challenges and produce the most accurate results available. Shop-hardened and temperature-compensated, it allows anyone, anywhere to measure in 3-D with previously unheard of precision.
For more information visit: www.gage.faro.com
|
|
|
|
|
|
Non-contact Vision Measuring machine is a photoelectric measuring system of high precision and efficiency. It is composed of a series of components, such as CCD color camera of high resolution, continuous zoom lens, color monitor, video crosshairs generator, precise linear scale, multi-functional Digit Readout (DRO), 2D measuring software and high precision worktable.
It is mainly applied in 2D measurement, sometimes in 3D as well. It is widely used in different kinds of precision finishing industries, such as electronic part, precision mold, precision tool, spring, screw processing, plastic, rubber, oil seal valve, camera part, pedal cycle part, motor part, conductive rubber and PCB processing. It is a must for the metric room, laboratory or workshop of various sectors concerning to machinery, electronics, gauging instrument, watch, plastic and light industry as well as academies, research institutions and measurement-inspecting department.
Rational has standard VMS-G series, advanced VMS-F series, CNC VMS-H series and so on. Rational Video measuring system is charactered with good quality, reasonable price and good after-sale services
|
|
|
|
|
|
Coordinate Measuring System can measure all basic geometrical elements such as point, line, plane, circle, arc, ellipse, cylinder, cone and sphere, easily measure 3D size, shape and position error of all components and can complete measuring of the majority work pieces of a modern manufacturer. It is mainly used in the machinery, electronics, moulds, automobiles, space and aviation industry. it has the below speciality,
1. Integrated granite working table and sliding bridge structure improve the movement performance and ensure precision and stability of the whole mechanical system.
2. High precision air bearings with pre-pressing design and free fray are adopted for all guide rails to provide more stable operation and ensure excellent dynamic performance of the machine.
3. High precision natural granite is adopted for three axis guide rails, so that the three axes have the same temperature characteristics, good rigidity and will not deform with the time going on.
4. RENISHAW self-adhesive strap metal reflection grating ruler is with high precision, good stability and convenient debugging.
5. Coordinate Measuring software Rational Dmis with powerful functions provides you with most perfect measuring solutions, simple and friendly measuring interface, which is easy to learn and use.The device is also equipped with a highly effective air processing system to ensure excellent quality of compressed air.
|
|
|
|
|
|
The HandyPROBE™ arm-free probing system, powered by the C-Track™ dual-camera sensor, relies on a combination of advanced photogrammetry and powerful digital image processing. This unique duo generates high accuracy data, and increases the reliability and speed of the measurement process, whether on or off the production line.
The HandyPROBE is a 100% portable CMM that gives you total freedom of movement, and allows you to increase your productivity and quality significantly!
Applications
Inspection
- Part-to-CAD analysis
- First article inspection
- Supplier quality inspection
- Conformity assessment of 3D models against the original
parts/production tooling
- Conformity assessment of manufactured parts against the originals
- Manual and automated statistical analysis
- Multi-shot measurement (up to 30 points/sec.)
Benefits
Handheld, portable device
Total freedom of movement
Automatic alignment setup
Measurement Range Volume Extension
User friendly
Continuous calibration monitoring
Excellent ROI
Automatic data collection & report generation
Technical Specifications
Weight (HandyPROBE): 450 g (1 lb)
Dimensions (HandyPROBE): 204 x 159 x 97 mm
Weight (C-Track): 5.5 kg (12 lbs)
Dimensions (C-Track): 1089 x 174 x 119 mm
Measurement speed: 30 points/s
Single point accuracy: 25 μm
Volumetric performance*: 85 μm
Operating volume: 7.8 m3 (273 ft3)
Operating temperature range: 15-40 °C (59-104 °F)
Operating humidity range (non-condensing): 10-90%
Universal power supply: 100-240 VAC/50-60Hz
Certifications: EN 301 489-1, EN 301 489-3, EN 300 220-1
*Test methods in compliance with the ASME B89.4.22 standard
|
|
|
The VideoCAD series 1, 2, and 3 of Dr. Heinrich Schneider Messtechnik is designed for the precise and fast measurement of two-dimensional geometries. The devices are especially appropriate for profiles made of plastic, aluminium, wood, rubber, rubber-metal and metal, as well as for stamped parts of any kind, templates, gaskets, layouts, and many more – also in serial production.
|
|
The Merlin 300 is a 2-axis video edge measuring system designed to enable quick, accurate repeatable measurements on multiple planes in the X and Y axis, via a high resolution video image.
With a high brilliance LED surface and sub-stage illumination,
Merlin is mainly intended for measurements of parts which
have good optical clarity and contrast like metal and plastic moulded components.
Comprehensive video tools are accessed by a video dedicated microprocessor employing the latest touchscreen technology, with a unique simplified one touch tool teach facility
|
|
|
The MICROHITE is thus a model of ergonomics and user-friendliness and precision. Recently marketing (January 2005) the MICROHITE exists in Manuelle version or Numerical control. Powerful software PCMDIS equipping the MICROHITE is common to all the range of the machines Hexagon Metrology. Its extremely competitive price at the head places the MICROHITE of the machines of measurement of its generation.
|
|
|
|
|
|
High-accuracy 3D coordinate measuring machine
Leitz Micra
The Leitz Micra coordinate measuring machine is naturally predisposed for quality inspection of small high-precision parts. It unites high accuracy and exact single-point inspection with accurate scanning of surfaces and profiles. The miniaturized LSP-X1c high-tech scanning probe system provides Leitz Micra's foundation.
The Low Force Probing mode lets users inspect delicate surfaces. In this mode, minimal probing forces assure that filigree objects are gently inspected without damaging valuable surfaces.
In addition, the Leitz Micra has a small footprint and can be transported quickly and flexibly. The light-alloy frame specially designed for added rigidity, combined with the exclusive portal configuration of the Y traverse utilizing the TRICISION® architecture, optimizes the relationship between rigidity and weight. This way, the highest possible accuracy and outstanding long-term stability are achieved.
Leitz Micra has a measurement volume of 500 x 400 x 300 mm. Its volumetric longitudinal measurement uncertainty is 1,0 + L/400 µm. In addition, it can run either under the PC-DMIS or the Quindos software. It is particularly well suited for quality assurance in precision engineering and optics, the electronics and telecommunication industries, medical engineering, watchmaking and powertrain industries.
|
|
|
The LAMBDA carries out the quadrature of the circle which consists in associating great capacities of measurement, a high rate of travel and an excellent measuring accuracy. One or more gantries ensure measurements on sizes of machine being able to reach more than 20 meters.
|
|
MEASURING: QUALITY CONTROL AND MANAGEMENT INFORMATION
You, like all our customers, demand ever higher production capacity, quality and accuracy. This is particularly important for standard size products which subsequently undergo further operations, such as welding, bending and/or punching, performed by robots or other automated systems
|
|
|
Continuous development has made scanning technology an indispensable technical production factor. Bridge-type measuring machines from Carl Zeiss, with VAST® and Navigator® technology for example, not only ensure a high level of process stability, they also fit seamlessly into the rough production environment as a result of their sturdiness and compactness. You can read more about the classic PRISMO®, as well as smaller measuring machines such as ACCURA® and CONTURA® G2 here.
|
|
|
The range of particularly wide machines TOTAL STATUS offers more than 60 models different in term from size (500 to 2000 mm), from equipment and environmental conditions. Certain models require a air-conditioned environment, others can evolve/move in a medium of workshop having variations in temperature of 15° and more. Capable of point-to-point measurements, with continuous scanning by contact or optics, machines TOTAL STATUS are equipped with powerful software PCMDIS common to all the range of the machines Hexagon Metrology.
|
|
|
|
|
|
Our proven SOLO solution has been expanded by new software and calibration techniques. By adding an extra camera the total field of view has doubled to 70x320, opening up for a variety of new applications.
Short object-to-camera distances allow for easy setup in crowded environments and with excellent accuracy. Just point the cameras in the direction of the object to be measured and immediately capture 3D coordinates of the probe touch point.
New technology has allowed us to bring the price down to make it the most cost-effective portable CMM available in the market today.
Metronor has delivered portable CMM systems to the most demanding industries for well over a decade and proven that our systems will deliver superior accuracy where and when required.
- High accuracy on large objects
- No setup - just measure
- Handheld Wireless / armless / beaml
- Flexible and versatile
- Affordable capability
- Exceptional 700 field of view
- Unique solution for shaft alignment
- Ideal for narrow and crowded environments
- ess probing
- Tool certification within minutes
- Facilitating 100% assembly line up-time
|
|
|
Metrotomography allows you to measure the interior of a workpiece: all recorded data can be applied to all areas of quality assurance and be evaluated. Non-destructive testing technology, such as assembly inspection, damage and porosity analysis, material inspection and defect checks, is possible as well as traditional evaluation, reverse engineering applications or a comparison of geometries. More on Metrotomography®, the fusion of metrology and tomography, can be found here.
|
|
|
|
|
|
Description
The Dr. Heinrich Schneider Messtechnik coordinate measuring systems meet all of the requirements placed on high measuring accuracy, precise movement, easy operation and flexible use.
Their efficiency is due to a variety of factors: a stable basic unit, excellent optics, various probe and laser systems, flexibly usable sensors and a fast, universal control system. The sturdy granite construction guarantees a rigidity, and thus ensures the system's insensitivity towards mechanical and thermal influences. Contactless measuring scales guarantee backlash-free operation and high measuring accuracy.
The measuring stages are motordriven, the speed of the CNC control can be adapted to the respective function. Moreover, the measuring stage is electronically corrected in all axes; this calibration can be checked at any time and corrected if necessary. The telecentric optics and diode light - with programmable intensity and adapted angle of incidence - are specially coordinated to each other. This eases the measuring of complicated workpieces and even of pieces with low contrast - also in incident light.
|
|
They are basically built for measuring rotation-symmetrical parts such as crankshafts, camshafts, gear shafts, drive and steering shafts.
Especially for the crankshafts and camshafts, all kinds of geometric elements can be measured: diameter, length, radius, oil bore holes, flange bores (lateral image), stroke length, stroke offset, stroke angle, symmetry, radial run-out, axial run-out, roundness, grooves, groove width, groove symmetry, and many more.
|
|
|
Highly accurate determination of surface parameters, determination of contours and forms: with the different configurations of Contourecord, Surfcom and Rondcom measuring machines, Carl Zeiss offers a powerful line of measuring machines. Whether with a single instrument or a modular complete system, there is an ideal solution for every application. Find out more about the machines, configuration and performance features here.
|
|
|
Machines of measurement from which guidance is protected. this technology makes it possible to work in aggressive mediums of workshop, there or a machine of traditional gantry measurement quickly becomes inoperative
|
|
|
|
