STANDARD EQUIPMENT
Slide with six long guides
Counterbalance cylinders for the slide (for models R-RE)
Centralized lubrication system
Air equipment with filter-lubricator, reduction units, pressure
gauges and air receivers
Three-phase electric motor
Electric equipment with braking angle control, push-buttons
simul-taneity, double solenoid valve, strokes counter, pressbutton
and control board
Lubrication automatic pump
Hydraulic release device (mod. R-RE)
|
|
|
The technicality and experience of our design offices enables us to handle the most diverse requests and to develop machines to special specifications.
|
|
|
|
|
|
The various PCK-press models are designed to cope with the severest demands in the production field. The design of these presses combines strength and simplicity of use. They are easy to operate, easy to maintain, and carry all required safety monitoring devices for the safety of the machine and the personnel. The PCK-press can be used as a stand-alone press or can be incorporated into an automated production line.
Basic equipement, common to the whole range:
• Capacities from 630 to 3 200 kN.
• C-frame made of flame cut welded steel plate.
• Electro pneumatic clutch-brake combination.
• Variable stroke (semi-automatic adjustment).
• Motorised ram height adjustment.
• Hydraulic overload safety device.
• EC-approved.
Optional equipement:
• Modified dimensional specifications.
• Tool-clamps and die lifters.
• Tool loading arms.
• Pneumatic blank holder.
• Electronic roll-feeder or other feeding devices.
• Force indicator.
• PLC-control.
• Feed line.
• Finished part packaging and handling.
• Soundproof housing.
• Custom made modifications and designs.
|
|
Presses and perforates plastic bottles, Tetra-pak, metallic cans, spray, etc. It remakes technical characteristics of material for better and simpler it’s further processing: separating, washing, transporting, etc.
Cylinder press immediate, without waiting compress even big quantities of material - till 5 tons/h. of plastic bottles;
Plastic isn't destroyed or ruined, maintains it’s value so a more simple and precise optical selection can be done. There is no breakage of iron threads of presses bales because there are no bottles with compressed air inside.
From destructed cans it is possible to obtain pure recycled metal.
Cylinder press is used in plastic bottles recycling and food industry.
|
|
6t / 15t
High performance, they will carry out your most demanding jobs accurately and reliably.
25t / 45t / 80t
Longlife work machines will give you unequalled productivity and quality gain for the future!
|
|
Standard Features
• Minster's Production Management Control
• One-Piece Cast Frame
• Heavy Duty Bed for Stability and Precision
• Flywheel Drive Arrangement for Maximum Press Efficiency
• Heavy Drive Connection and Rigid Slide
• Dynamic Balancer System
• Hydraulic Quick Lift
• Sealed Crown
• Fully Hydrostatic Slide Guiding
• Thermal Control Package
• Powered Shutheight Adjustment with Electronic Readout
• Cast Iron Bolster Plate With General Purpose T-Slots
• Flywheel Brake
• Four Vibration Mounts
|
|
|
|
|
|
Features and advantages:
CE certification.
Exceptional build quality and design for outstanding value
The press body's steel structure is welded and heat-treated to ensure maximum rigidity and durability.
The slide has 6 guiding surfaces with permanent central lubrication for high accuracy operation.
Highly rigid build and precise carriage guiding ensure very low tool (die) wear for maximum productivity.
Our 100-200 ton presses offer semi-automatic stroke adjustment, and the 250 tone and 315 tone models feature automatic stroke adjustment.
Motorized adjustment of carriage height on our 100-315 tone models
Hydraulic overload protection device after 63 tone models
All presses have a combined clutch-brake device.
All movable parts of the presses are reliably protected with cut-outs, shields and fences to ensure worker safety.
Reduced noise level and vibrations thanks to angular gear drive in oil bath.
High quality components ( pneumatic, hydraulic and electronic parts ) are procured from the leading European manufacturers.
Conceptually and technically advanced electronic control units are featured all our presses:
Control units are CE certified and fulfill the requirements of EN 954 group IV.
The control unit's components comprise of selected electronics from first-rate suppliers such as Telemechanique, Siemens, Preventa, and PILZ, providing safe and flawless performance in all operating modes.
All standard control units may be adapted to control any type of feeding lines according to client specifications.
|
|
Standard Features:
- Minster Production Management Control
- Dynamic Balancing for a wide range of upper die weights
- Minster heavy duty hydraulic clutch and brake
- 8-point bronze lined hydrostatic gibs for guiding stiffness and accuracy
- Low deflection bed with integral oil sump
- Patented Minster MonitorFlow recirculating lubrication system with continuous flow
- Hydraulic arrangement on PM3-125 slide adjustment screws
- PM3-200 has hydraulically-supported screw threads
- Minster programmable limit switch control with a 64 program storage
|
|
|
The DALCOS® LF perforation lines are designed to produce fully punched, notched and cut-to-size panels ready for bending. They offer a high output and an excellent performance/price ratio.
|
|
|
• Electro-welded steel frame • Alloy steel gear guard, oil-bath • Alloy steel cam shaft • Steel connecting rod • Electro-welded ram with 4 or 6 bronze guides • Pneumatic brake/clutch unit • Double mechanism valve • Control panel with leds for self diagnosis • Stroke counter • Reverse movement selector switch • Braking angle control • Automatic lubrification with adjustable flow and oil re-cycle • Extracting unit • Device for fast adjustment of ram • Accident protection devices • Balancing cylinders
|
|
High speed production lines consisting of:
Sheet feed stamping press to produce cap shells, type END-O-MAT.
Rotary cap former with pre-curling, curling and lugging, type CAP-O-MAT.
Lacquer hair aspiration with antistatic unit.
Liner for plastisol compound,
type END-O-MAT.
Drying and curing unit.
Video inspection.
Packaging units.
Conveying units.
|
|
OPTIONS
• Inverter • Two speed motor • Additional table • Tie-rod assembly • Push-button panel, separated • Cover for table hole • Hydraulic safety device (CNR6) • Ram motorised CNR6) • Water-air cushion
|
|
|
|
|
|
HB 60E
Bihler/Minster high-speed press
With the HB 60E Bihler now includes a high-speed press in its range of products. It is based on the latest Hummingbird of the US partner Minster Machine Company. Especially for the European market Bihler combines the proven features of the Minster press with the adapted, user-friendly press control EC-P, an optimized machine design and an integrated operator protection. The HB 60E was designed specifically to meet the needs of stampers involved in the high volume production of intricate parts requiring extreme accuracy, uniformity and process security. As non plus ultra amongst the high-speed presses this machine is suited for the manufacture of highly complex parts especially for the automotive and electronic industry.
In stepless version the 600 kN press is capable of 1000 SPM with a stroke length of 15 mm making the HB 60E the fastest machine of its type in this tonnage range. Ideal for parts such as electrical laminations, small intricate parts for office machines and electronic equipment, automotive parts, long and short runs. The flexibility of the optional infinitely adjustable stroke and standard quick access slide features with motorized shutheight adjustment expand the use of the machine from punching and flat blanking to formed parts. The rigid guiding system, combined with the hydraulic clutch/brake system allows for fast starting and stopping, providing the ultimate in part precision, die life and productivity.
|
|
Standard Features:
- Minster's Production Management Control
- Cast Construction for Reduced Vibration
- Massive Bed for Exceptional Rigidity
- Crown and Eccentric Shaft Provide Strength and Resist Deflection
- Main Bearing Support Block
- Tie Rods Aid Rigidity
- Heavy Slide and Connections
- Shutheight Adjustment and Indication
- Eight Point Gibbing for Precision Slide Guiding
- Drive Arrangement Options for Maximum Press Efficiency
- Minster MonitorFlow... Continuous, Monitored Press Lubrication
- Minster Combination Air Friction Clutch and Brake
|
|
|
Machine up to 500 tonnes capacity have high quality steel one piece fabricated frames. Larger machines are manufacted with four piece construction, where the crown, two uprights and the base tightly hed togheter by four hydraulically pre-loaded steel tie rods. The slide is of high quality fabricated steel scontruction with eight adjustable bronze lined gibways. All machines are equipped with an adjustable hydraulic overload protection system and have a separate electrical control cabinet. Machines control include the following: slide adjustement indication, variable speed, lubrification monitor, bearing temperature display.
|
|
The eccentric presses series "Swan neck” are realized in composed and normalized steel; they are strengthen to the most stress parts. This type of construction is apt to support particularly onerous conditions with a high degree of rigidity.
All the presses of these series are the fruit of a longest experience. Is for this reason that, they are studied in the way more rations them under l' aspect works them that under that one of the security.
In fact they are all certified " CE" and complete where previewed of: devices run change, adjustable hydraulic overload, motorized regulation ram, variable speed, accident-prevention photocells and all the devices previews into effect normative enforced.
|
|
|
2PACK double point double sided presses are the result of a long and fruitful cooperation with our customers. A welded and stress-relieved monobloc frame, a generously dimensioned drive and a long high-precision ram guiding system ensure perfect mechanical operation. The absence of structure below floor level avoids the need for special masonry work, while still providing an ergonomic working height. The tool zone is designed to receive an enormous diversity of tools, especially follow-on tools.
|
|
Double point connecting rod eccentric presses for different cold stamping utilization: cutting, stamping, punching, bending, calibration, sizing, etc.
Press features:
State-of-the-art electronic control by SIEMENS.
Visual indication of current operation
Visual indication of main characteristics
Press meets all safety standards:
European standards for mechanical presses EN 692
Instruction for safety work UVV.11.062
Hydraulic safety device
Automatic change of stroke
Motorized adjustment of carriage position
Roller guides of carriage or
Sliding guides of carriage
Longitudinal shaft or
Transverce shafts
CE approved
|
|
Standard Features
• Hydraulic Clutch and Brake Providing Fast Starting and Stopping.
• Four-Piece Tie Rod Construction Frame.
• Single-Geared Drive with Opposed Twin Helical Driving Gears. (DAC Presses)
• Large Air Bag Pnuematic Counterbalance Cylinders on Inner and Outer Slides.
• Minster patented "Monitorflow" Recirculating Oil Lubrication System.
• Die Plumbing Regulators and Manifold for Front and Rear of Press.
• Air-Operated Flywheel Brake.
• Press Arranged for Front and Left Mounted Feed.
• Quick Lift in Outer Slide for Quick and Easy Die Access (DAC-H200)
• Integral Dynamic Balancer. (DAC-H200)
• Flywheel Drive Providing Higher Speed Capability (DACH Presses)
• Precision Slide Guiding System.
|
|
