The proven Lokotrack mobile screens are designed for high screening performance combined with good mobility. Their excellent capacity and easy adaptability to different crushing and screening processes guarantee suitability for a wide range of quarrying and contracting applications.
The ST Series track-mounted mobile screens have heavy duty frames and proven components to give long service life in most demanding screening jobs. With the ST Series, you can choose flexibly and accurately the end product fractions to be screened.
The SW Series wheel-mounted mobile screens are designed to guarantee superior mobility on wheels and the ability to produce multiple end products with constant, high capacity.
The patented design of these units allows the user to travel over roadways without special permits and set up the screen in minutes once on site.
The CV Series wheel-mounted mobile screens offer construction and recycling contractors an easy to operate, highly reliable screening plants on wheels, able to handle a wide variety of materials. Processing the materials on site minimises purchase requirements and reduces expensive hauling costs.
|
|
Designed and developed to fulfill the demands of todays high Production
Producer, the Finlay 693 has surpassed all expectations. Available in three
options, the Supertrak model offers maximum on site mobility incorporating a twin undercarriage which can be controlled from a hand held radio control. The Superscreen model is a fully road-going version fitted with 5th wheel coupling and triple axle bogie. The third variation is a combination model fitted with both twin track undercarriage and triple axle bogie (which is detachable for onsite tracking). Impressive features include a 6.1m x 1.5m (20' x 5') 2-deck screen, three hydraulic folding conveyors, high capacity belt feed hopper and low level greasing. Washing equipment can be fitted to the screenbox if required.
|
|
Screening - 883
The Finlay 883 is designed to work as an aggregate screener after a primary crusher or on it's own as a frontline screening machine. Applications include quarry waste, construction and demolition debris, topsoil and aggregates. Processing at a rate of up to 500 tonnes per hour, the key to the 883 is its adaptability, whatever the application or industry.
Additional Information
* Low level feed height
* Hardox steel pan apron feeder
* Heavy-duty screenbox with huge clearance between decks allowing a larger middle grade product to be processed.
* Screen box features quick change mesh clamps
* Adjustable screen angle between 13° and 19°
* Options include:
o Radio remote control movement.
o Remote tipping grid
o Heavy duty tines or punch plate in top deck of screen.
o Cascade fingers in bottom deck.
o Magnet on oversize conveyor.
o Heavy Duty bofar bars in top deck
o Extended fines and middle grade conveyors
|
|
Screening - 312 Hydrascreen
The Finlay 312 Hydrascreen is a versatile screening unit that offers the operator the capacity and ability of producing high profit graded materials at a relatively low cost. Options include single or twin deck vibrating grid, chopper unit, catwalks and washing equipment. Typical applications include sand and gravel, limestone, topsoil, coal and slag.
Standard Features
* Tipping Grid
* Deutz Air Cooled Engine
* Twin Deck Screen 10' x 4' Top Deck, 8' x 4' Bottom Deck
* Single Braked Axle
* Easy Access Engine Compartment.
* Options include:
o Washing Equipment
o Remote Control Tipping Grid
o Twinset bogie unit
o Cutter Unit
o Vibrating Grid
|
|
The rugged and easily mounted EASYSTAR star screen deck separates compost, bark, biomass, etc. into oversized and undersized particles – extremely reliably and with low noise levels. With its easily mounted footrest substructure, the simple roll-off version allows quick and flexible semi-mobile use.
When used in conjunction with a shredder, overlengths (shredded waste wood, green waste, root wood, etc. ) are cut off effectively, resulting in simple, cost-effective material treatment.
Advantages at a glance
* quickly deployable with mounting on roll-off platform
* high throughput with precise selectivity – even with moist materials
* simple speed control at the screen deck to change particle size in seconds
* ideal for removal of overlengths in conjunction with shredder
|
|
|
HITACHI Track Mounted Screen was developed by accumulated technology. It's featuring precise screening and superior transportability. Our highly advanced screen realizes reliable performance with environment friendly in various job sites as follows. Landfill, Waste management, Recycle, Quarry, Mining, Demolition and so on.
|
|
|
|
|
|
S-4
The Extec Double Screen
Based upon the world leading S-5, the S-4 is designed for operation where the massive throughput of its larger sibling is not required, but there still exists a requirement for precision screening only available from a Doublescreen.
The S-4 produces a huge screening area (at least equivalent to a traditional 16’X5’ (4.8m x 1.5m) screening system) but with to independently adjustable screen boxes for precision screening and massive production.
The S-4 encompasses such features as:
* Spreader plate - this is of unique Extec design to spread material across the full width of the screening facility while maintaining the velocity of the material particles
* Screening facility consists of two individual screening units, each having its own separate drive and each being independently angled
* The split screening facility enables the first screen box to be used as fines extractor even of the most difficult sticky material while the second box operates as a grader. The net result is that the Doublescreen produces grades of material of the most precise specification that we have ever seen from a mobile screening system
* Chassis - this is of the most modern computer assisted design capable of withstanding the stresses generated by high speed highway towing or track slewing over the roughest of terrain
|
|
|
|
|
|
S-5
The Extec Double Screen
The ultimate mobile screening system designed for the truly serious contractor or quarry operator.
The S-5 represents the greatest innovation in mobile screening systems as the S-5 resolves the conflicting principles previously associated with providing larger screening areas on mobile plant.
Massive throughput, mobility and a class leading screening area results in the ultimate profit generator.
The S-5 encompasses such features as:
* Heavy duty tipping grid activated by remote control - this will accept feed from a wheeled loader or excavator. Large hopper with variable speed belt-feeder, which has heavy-duty roller bed and heavy-duty belting
* Two individual screening units, each having its own separate drive and each being independently angled. The throughput of this screening facility parallels that of a conventional screen box of 7.62m long
* Chassis - This is of the most modern computer assisted design capable of withstanding the stresses generated by high speed highway towing or track slewing over the roughest of terrain
|
|
|
|
|
|
THE BRAND NEW S-6 DOUBLE-SCREENING SENSATION.
Extec have launched the ultimate large production screen; the totally brand new - S-6.
The S-6 is based around the revolutionary Doublescreen concept that has taken the screening world by storm. Designed for the aggregate producer who requires large throughput, true mobility and clean gradings, the new S-6 encompasses such features as:
* Screening area consists of two individual 10x5 screen boxes, each possessing their own separate drive, and each being independently angled.
* The screen box arrangement presents a massive screening area, yet allows for an incredibly clean product through the independent set up of the two screen boxes.
* Longer, chevron belted side conveyors, in order to feed directly into a cone crusher, and/or possess vast stockpiling capacities.
* Longest tail conveyor in its class for even greater stock piling capacity.
* Faster running belts in order to facilitate high rates of production.
* Patented screen box lift mechanism to ease mesh change.
* New stronger chassis design for the most demanding of environments.
* Longer tracks in order to produce a stable screening platform.
|
|
S-3
The newest member of the S-Series is a single screen-box screener that uses the same state of the art design technology to construct a screener for today’s requirements.
Perfect for the quarry or recycling operation where durability, production and mobility are paramount. The S-3 encompasses such features as:
* Spreader plate - this is of unique Extec design to spread material across the full width of the screening facility while maintaining the velocity of the material particles
* Chassis - this is of the most modern computer assisted design capable of withstanding the stresses generated by high speed highway towing or track slewing over the roughest of terrain
* Extec's unrivalled high frequency screen-box designed for easy change of screen meshes and unsurpassed screening efficiency
|
|
|
|
|
|
THE BRAND NEW INSPIRATIONAL TRIPLE DECK S-7 SCREENER
Extec have launched the ultimate large production screen; the totally brand new - S-7.
The S-7 is based around the revolutionary Doublescreen concept that has taken the screening world by storm. Designed for the aggregate producer who requires large throughput, true mobility and clean gradings, the new S-7 Possesses such features as:
* Screening area consists of two individual 10x5 screen boxes incorporating 3 decks in each screen box, allowing for a more concentrated screen.
* Each Screen box possesses its own separate drive, and each being independently angled to aid the screening process.
* The screen box arrangement presents a massive screening area, yet allows for an incredibly clean product through the independent set up of the two screen boxes.
* An extra side conveyor that enables the S-7 it to produce up to a massive total of 5 product materials.
* Longer, chevron belted side conveyors, in order to feed directly into a cone crusher, and/or possess vast stockpiling capacities.
* Longest tail conveyor in its class for even greater stock piling capacity.
* Faster running belts in order to facilitate high rates of production.
* Patented screen box lift mechanism to ease mesh change.
* New stronger chassis design for the most demanding of environments.
* Longer tracks in order to produce a stable screening platform.
|
|
Robotrac
In a worldwide context this is the definitive track mounted scalping screen which employs such a highly efficient screening process it doubles as a grading screen in many applications.
Designed to scalp heaviest of material yet its ability to screen finer sizes is phenomenal for a scalper. Its sheer manoeuvrability on the ledge of a mountain quarry or on the demolition site of a Tokyo 'pencil' building has earned it the reputation of being one of the world's most versatile screens in terms of production and mobility. Key features include:
* Fitted with the world-renowned Extec double deck vibrating grid
* High speed scalping of sticky clay and fines from heavy rock and concrete
* Heavy-duty impact feeder absorbs shock loads and maintains smooth flow of material to the stockpiling conveyor
* Self-propelled and highly manoeuvrable on site
* Remote control operation by excavator operator
|
|
E-7
Extec have announced a brand new tracked screen – the E7, a heavy-duty track mounted self-propelled open flow screening and stockpiling system. This revolutionary machine has been purpose built for the recycling and quarrying markets.
The E-7 has been developed over the last 18 months through Extec’s acclaimed R&D programme. Based on in-depth customer and market analysis the E-7 has been developed in order to deal with customers real requirements, which traditional screening solutions are unable to adequately cater for.
These include:
* Screening heavy over-burden at the quarry face
* Pre-screening/scalping prior to being fed into a crusher
* Recycling construction and landfill waste
* Separation of “sticky” aggregate
|
|
|
The Fintec 570 has been designed by our experienced engineering team so that we could offer the customer a high production machine that would feel at home in any quarry application. The large screenbox allows the operator to feed the F570 with a wheel loader or to work in tandem woth any crushing plant to produce the final high specification grades of material.
|
|
|
|
|
|
The Fintec 542 Tracked Screen is a robust, highly durable machine, designed specifically for the Recycling and Contractor market. It has a 3650mm x 1500mm (12’ x 5’) two bearing screenbox with increased screening angle built into the bottom deck of the screen. This feature coupled with the larger screening surface area and increased throw on the screenbox enhances screening efficiency and capacity, through the actual screenbox itself.
The Fintec 542 Tracked Screen has a unique user-friendly folding access walkway fitted as standard around the screenbox, thus providing the operator with easy access for maintenance.
Also, the belt feeder has a 8m³ capacity and is fitted with a radio controlled tipping reject grid as standard.
Our machine is driven by a CAT 3054C water-cooled diesel 74kW (99hp) engine with an Engine Shut Down Protection System. The main conveyor is fitted with a 1050mm heavy-duty belt.
The tracks are 500mm wide to cater for various ground conditions and are pendant track controlled.
|
|
|
|
|
|
The Fintec 640 is a heavy duty scalping screen designed to work in tandem with our Fintec 1107 primary jaw crusher or as a stand alone 3 way split screener; The 640 is constructed for easy mobility and transportation; All conveyors are hydraulically foldable and walkways are fixed, for quick transport and set up time on site. The 640 uses a 74kw (99hp) engine to power the hydraulics throughout the machine.
The Fintec 640 screen can be feed by loading shovel, excavator or crusher. The hardox steel apron feeder provides a solution to aggressive and previously impossible applications. The apron feeder feeds directly on to the variable angle screenbox for maximum screening efficiency. There are a multitude of options available for the screening media on both the top and bottom decks of the screenbox, all of which are available with varying apertures. Screen meshes for the top deck of the 640 are all interchangeable with the Fintec 542. All conveyors are fitted with heavy duty impact bars in feed boots and impact zones to prolong belt life.
|
|
The VS60 is a compact standalone screen unit designed to sort and separate fine material from rubble, asphalt, concrete and excavated material etc.
The container-mobile twin deck screen is also an ideal complement to the RM Compact Recycler RM60 (also compatible with RM70). The two screen decks deliver the most precise level of grading by pre-screening fine grained material and considerably reducing wear in the crusher. The discharge height can be adjusted by inserting 2 additional skids.
Power can be supplied from the crusher generator - a huge advantage at more remote sites. Also available with side discharge belt, hopper extensions and container-mobile transport option.
|
|
RUBBLE MASTER CS series screens are compact linear oscillation screens that can be transported like containers. They are flexible as far as feed material is concerned an sort crushed material such as building rubble and natural rock very efficiently. Power is supplied from the crusher generator - a huge advantage at more remote sites.
The CS3600/2 twin deck screen is perfectly matched to the powerful RM70 and RM80 crushers. Its throughput capacity is optimised according to the angle of the screen, mesh gap and the type of material to be processed. Even at high throughputs the CS3600/2 impresses with its reliable grading ability and low maintenance requirement thanks to self-cleaning screen decks.
The three conveyor belts achieve impressive discharge heights as well. The screened material belt is safely integrated into the framework and is folded away hydraulically prior to transport. The CS3600/2 can be transported to job sites using a truck equipped with a drag-on winch.
|
|
|
|
|
|
The TS3600 is the economic solution for producing high-quality defined grain sizes, regardless of whether it's round grain from walls or for refining building rubble that can be graded using a screen.
The tracked double-deck screen can be operated as a standalone screen to separate excavated soil, sand and gravel, plus building rubble mixed with high levels of earth and fine grain material. Thanks to the hydraulically opening feed hopper with oversized grain grating, the TS3600 can also be fed direct from a mobile RM100. Three defined final grain sizes can be produced in a single pass in combination with the RM100 and OS100 power package equipped with oversized grain re-feeding system.
The screen can be operated by one person alone and the system is available with a radio remote control. All maintenance jobs can be carried out quickly and easily, thanks to perfect accessibility.
For transport purposes the belts are moved hydraulically into the transport position so the TS3600 with its unique, compact dimensions is ready straightaway for transportation from one job to the next.
|
|
RUBBLE MASTER CS series screens are compact linear oscillation screens that can be transported like containers. They are flexible as far as feed material is concerned an sort crushed material such as building rubble and natural rock very efficiently. Power is supplied from the crusher generator - a huge advantage at more remote sites.
The CS2500 single deck screen is perfectly matched to semi-mobile RM60 crushers. The throughput capacity of the linear oscillation screen is optimised according to the angle of the screen, mesh gap and the type of material to be processed. Even at high throughputs the CS2500 impresses with its reliable grading ability and low maintenance requirement thanks to its self-cleaning screen deck.
The two conveyor belts achieve impressive discharge heights and are integrated safely into the frame of the screen unit. They fold hydraulically for transport so the CS2500 can be loaded onto a truck equipped with a drag-on winch.
|
|
| ... products without technical information |
| |
The Future.Pad® 84 T-N is a IP54 /MIL-810F, full rugged handheld mobile tablet computer with 8,4" touch screen in ultra robust mechanical design, featuring Intel® Atom™ Z-processor up to 1.6 GHz, up to 2GB SDRAM and >60GB HDD / >16GB SSD storage.
It provides various features, such as sunlight readable display, GPS, 3.5G HSDPA, 1D barcode reader, RFID, RAM mount, docking station.
The Future.Pad® 84 T-N provides a powerful mobile computing platform with an 8.4 inch TFT color LCD and optional sunlight readable touch screen.
It has built-inWiFi 802.11/b/g/n and Bluetooth to enhance the mobility and smooth data access for various vertical markets. Furthermore, the Future.Pad® 84 T-N has the strictest measurement to protect all your sensitive data by implementing TPM encryption and fingerprint security features. The long lasting battery life can provide an uninterrupted use for 4~8 hours.
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
|
|
|
|
X44 SBS
The totally new Extec X44 SBS Cone Crusher will undoubtedly raise the benchmark for crushing equipment design, as Extec have built an unrivalled reputation for providing its customers with innovative and high quality products. The design and capacity of the X44 SBS have been specifically adapted to the markets real requirements, and to fully complement, and strengthen, Extec’s existing crusher portfolio.
Some of the new features taking crusher design to a new level include:
* Diesel hydraulic power via CAT C-13 Engine – 328 kW / 430 hp which provides hydraulic transmission without clutches.
* Telsmith 44SBS world leading cone.
* Variable speed, high torque for controlled and continuous feed.
* Feed hopper mounted on hydraulically contolled slew ring
* Hydraulic Closed Side Setting adjustment.
* Complete machine raises on its hydraulic legs to facilitate cleaning and servicing of tracks.
* Machine is self propelled by remote control or umbilical control hand set.
* Metal detector for feed hopper.
* Optional recirculating screen box for a guaranteed finished top size.
* Optional recirculating conveyor. This can also be deployed at 90 degrees for extra stock pile of different size material.
* Optional bogie system eliminates the need for low loader transport.
* Intelligent control system which allows communication of up to 8 machines operating in a line.
|
|
|
|
|
|
X38 SBS
The X38-SBS cone crusher pairs a world-leading cone crusher with proven design and manufacturing capability in order to provide a track-mounted mobile machine that sets new standards in crusher throughput and finished product shape.
This machine is powered by a C-9 diesel engine that meets all known emissions standards, and incorporates a cone crusher that is widely regarded as the leader in its field. Designed specifically for crushing and sizing minerals, the X38-SBS is able to work as independent unit, or as part of an integrated aggregate production line in harmony with the other members of the screening and crushing family.
Key features include:
* Diesel hydraulic power via CAT C-9 Engine 261 kW / 350 hp
* World leading cone crusher
* Variable speed, high torque for controlled and continuous feed
* Hydraulic Closed Side Setting adjustment
* Full Dust Suppression System
* Complete machine raises on its hydraulic legs to facilitate cleaning and servicing of tracks
* Machine is self propelled by remote control or umbilical control hand set
* Metal detector for feed hopper
* Optional re-circulation system
|
|
I-C13
This is a large heavy-duty tracked crusher incorporating the definitive Impact crusher made by Krupp Hazemag SA. Combining the revolutionary mobility, power and design of Extec crushers with the world reputation of Krupp Hazemag SA for Impactor performance. The following are among the features that set it apart:
* Very high production
* Vibrating feeder automatically meters the flow of material to the crusher
* Large crusher box promotes free flow of re-bar without blockage while fast track facility allows tangled material to clear machine
* Complete machine raises hydraulically for cleaning and service
* Full dust suppression system fitted
* Operated by remote control
* Self-propelled on site and travels on road without low-loader
|
|
|
|
|
|
C-10+
This compact self-propelled machine brings the revolutionary features of the Extec C-12+ to the smaller quarry or demolition site where operating space is limited, yet high performance required. Of most sturdy construction, its power management, coupled with unique jaw design, makes it an icon for this category of crusher.
The following are among the features that set it apart:
* Fully adjustable hydraulically controlled jaw.
* Diesel hydraulic power with CAT engine – 215 hp. Model No: C6.6
* Tremendous power and speed of crushing with Spectacular reduction in product size.
* Vibrating feeder automatically controls the flow of material to the crusher.
* Reverse crushing action to relieve blockage.
* Fast track facility clears machine of tangled re-bar eliminating down time so prevalent in conventional crushers.
* Complete machine rises hydraulically to facilitate cleaning and servicing.
* Self-propelled on site yet travels on road without ancillary transport.
* Vogel automated jaw grease system.
* SKF – Sealed for life bearings.
* Mild steel liners in hopper and feeder base as standard.
* Web & Flange Chassis.
* Increased capacity diesel tank at rear of machine.
* Improved main & side conveyor chute.
* Upgraded Electronics.
* Smooth and even tracking action.
Applications include:
* Rock Crushing in quarries and construction sites.
* Concrete Crushing and asphalt crushing in recycling yards or demolition sites.
* Asphalt Crushing.
|
|
|
|
|
|
C-12+
With over 1,500 units working world-wide the C-12 from Extec truly has become an icon in the world of tracked crushing.
Since its launch in 2001 the C-12 has been the benchmark others have measured themselves against with such revolutionary features as Vibratory feeder with automatic control to regulate the feed into the crusher; a hydraulic adjustment system to regulate the product size to be crushed: reverse crushing action to assist in clearing blockages; and a high crushing speed.
The newly designated C12+ is the result of Extec’s unrivalled R&D programme, and encompasses features designed to further enhance the profitability of the user at its core.
These features include:
* Extended tail conveyor as standard for even greater stockpiling capacity.
* Diesel hydraulic power via Caterpillar C-9 Industrial engine – 261 kW / 350 hp which provides hydraulic transmission without clutches.
* Large vibrating feeder with grizzly and discharge conveyor for fines. Hydraulic system automatically coordinates the flow of material from the vibrating feeder to the jaw.
* Hydraulic adjustment system to regulate the product size to be crushed.
* Uniquely small closed size setting.
* Operation of jaw can be instantly reversed to clear any blockage.
* Unique fast track system ensures the clear flow of reinforcing bar when concrete is crushed.
* Complete machine raises on its hydraulic legs to facilitate cleaning, servicing of tracks and to provide a stable base.
* Machine is self propelled by remote control or umbilical control hand set.
* Intelligent electronics.
* Bearing condition monitoring system.
* Vogel automated jaw grease system.
|
|
... see all the products in the category
Crushers
|
|
|
see the results for the following category :
