MCH series motion checkers are a palm size controller with integrated driver circuit built-in for 2-phase stepper motors. Both motion checker MCH-3 and MCH-5 series run unipolar and bipolar winding stepper motors. MCH-5 series has pulse/direction output signal so that it can be used as a standalone controller to connect any driver board.
MCH series motion checker is ideal use for quick stepper motor evaluation, stepper motor life testing, and educational training.
|
|
The UMX controller with USB connectivity is compatible with the PC78 and
PCIx controller families with 2-4 axes control. The UMX
supports up to 12 general purpose TTL I/O bits, 8 of
which are user definable.
The step pulse is a TTL level 50% duty cycle square
wave that supports velocities of 0 through 1,044,000
pulses per second. The encoder feedback functionality
supports quadrature encoders up to 12 MHz at a 4
times the encoder line resolution and is used as closedloop
feedback for the stepper axes or as independent
position feedback. The encoder feedback can provide
slip and/or stall detection. Each axis includes dedicated
+/- overtravel inputs, a home input, and an auxiliary
output.
|
|
|
|
|
|
Galil's DMC-21x3 Ethernet motion controllers are designed for extremely cost-sensitive and space-sensitive applications. These controllers are typically half-the-price and half-the-size of box-level Ethernet controllers. These intelligent, card-level controllers can be purchased with plug-in, multi-axis amplifier boards which eliminate wiring between the controller and drives. Amplifier boards are available for driving stepper, brush and brushless servo motors up to 500 Watts. Or, the ICM-20100 break-out board can be used for easy connection to external drives.
The DMC-21x3 series is available in one through eight axis versions and can be configured for control of step or servo motors on any combination of axes. The card-level controller measures just 4.25" x 7.0" for one through four-axis models and 4.25" x 10.75" for five through eight axes. Any mode of motion can be programmed including linear and circular interpolation, contouring, electronic gearing and ecam. As with all Galil controllers, programming the DMC-21x3 is simplified with two-letter, intuitive commands and a full set of software tools such as GalilTools for servo tuning and analysis, and the ActiveX Tool Kit for Visual Basic users.
|
|
The DMC-18x6 PCI bus controllers belong to Galil's latest generation motion controller family: the Accelera Series. Incorporating a 32-bit Risc-based microcomputer, these new controllers offer high-speed performance and processing power. Speed improvements include acceptance of encoder inputs up to 22 MHz, servo update rates as low as 24 microseconds/axis, and command execution speeds as low as 40 microseconds. While the DMC-18x6 offers performance enhancements compared to prior generation controllers, the programming language and 100-pin SCSI connector are virtually the same, making conversion to the DMC-18x6 quick and easy.
Like all Galil controllers, programming the DMC-18x6 is simplified with two-letter, intuitive commands and a full set of software tools such as WSDK for servo tuning and analysis, and an ActiveX Tool Kit for Visual Basic users.
|
|
|
|
|
|
Galil's CDS-3310 is a single-axis controller and drive system for precisely controlling a brush or brushless servo motor. It combines a high-performance, programmable motion controller with a 500W PWM drive in a compact, cost-effective package. The CDS-3310 provides a 10/100 Base-T Ethernet port and individual CDS-3310 units may be connected on a distributed network and programmed as a single controller. The communication burden is minimized because the host PC only has to talk with the master CDS-3310, which in turn communicates with the other CDS-3310 on the network.
The CDS-3310 incorporates a 32-bit microcomputer and provides such advanced features as PID compensation with velocity and acceleration feedforward, program memory with multitasking for simultaneously running up to eight programs, and uncommitted I/O for synchronizing motion with external events. Modes of motion include point-to-point positioning, jogging, contouring, electronic gearing and ECAM. As with all Galil controllers, programming the CDS-3310 is simplified with two-letter, intuitive commands and a full set of software tools such as WSDK for servo tuning and analysis, and the ActiveX Tool Kit for Visual Basic users.
|
|
|
|
|
|
The DMC-40x0 motion controller is Galil's highest performance, stand-alone motion controller. It belongs to Galil's latest generation motion controller family: the Accelera Series, which accepts encoder inputs up to 22 MHz, provides servo update rates as high as 32 kHz, and processes commands as fast as 40 microseconds-10 times the speed of prior generation controllers.
The DMC-40x0 is a full-featured motion controller packaged with optional multi-axis drives in a compact, metal enclosure. The unit operates stand-alone or interfaces to a PC with Ethernet 10/100Base-T or RS232. The controller includes optically isolated I/O, high-power outputs capable of driving brakes or relays, and analog inputs for interfacing to analog sensors. The DMC-40x0 controller and drive unit accepts power from a single 20-80 VDC source. The DMC-40x0 is available in one through eight-axis formats, and each axis is user-configurable for stepper or servo motor operation.
Like all Galil controllers, programming the DMC-40x0 is simplified with two-letter, intuitive commands and a full set of software tools such as WSDK for servo tuning and analysis, and an ActiveX Tool Kit for Visual Basic users.
|
|
|
Advantech offers application ready platforms ranging from industrial workstations and industrial-grade CPUs to motion control, encoder input and isolated I/O cards for general motion control (GMC) applications which could be widely applied in SMT/PCB, semiconductor, LCD manufacturing industries, and more. Furthermore, Advantech provides a full-range of industrial computing platforms that include high-brightness LCD displays, keypads, (up to) 20-slot backplanes and redundant power supplies for machine builders. Advantech's motion control cards have 3 and 4-axis inputs with pulse-type and voltage-pulse models. Finally, Advantech also provides a complete line of AMONet (Advantech Motion Network) distributed motion modules. All of the cards are supported by complete motion control libraries under DOS and Windows OS.
|
|
|
|
|
|
Motion Control Solutions
Baldor provides a wide range of motion control solutions for the automation industry by offering a choice of easy to use programmable motion controllers (positioners) with multi-tasking capability and drives (amplifiers) to suit many applications - the NextMove family is available in PCI format or standalone; the FlexDrive family covers a wide power range; and Ethernet Powerlink (e100 series) provides designers with real-time solutions. Offering between 1 and 12 axes of control, Baldor motion controllers are available with digital and analog I/O for complete machine control. The CAN bus interface can be used to expand the I/O configuration.
Motion control systems can be up and running quickly thanks to Baldor's Mint programming language. Mint is a versatile, yet easy to use, Basic like programming language. A wide range of programmable moves are supported including trapezoidal, S-ramp, linear and circular interpolation, helical interpolation, electronic CAM, gearbox and flying shear. User defined profiles can be added using the supplied embedded 'C' libraries. Mint also supports full control of the I/O and communications back to a host controller. Machine level networking and optional operator panel control can all be controlled under a single Mint application program.
Our latest generation NextMove controllers and intelligent drive, MintDrive, all support multi-tasking Mint, with the ability to write complex programs easily. The number of tasks is limited only by available memory.
A complete set of ActiveX components are supplied with the controllers, allow full motion and I/O sequencing to be performed on a host PC. Application programs can be written in popular programming languages such as Visual BasicTM, Delphi and LabView.
The motion controllers are complemented by a complete range of servo drives.
|
|
|
Electronics to control or trigger EC / DC motors
|
|
Drivers and Controllers for piezo actuators
To fulfill various requirements in terms of driving and control conditions for its piezo actuators (static, pulse, dynamic), the CEDRAT Group has developed 3 different families of standard drivers:
CA45 rack: Low cost & compact (1 channel) linear voltage amplifier for precise and quasi-static motion.
LA75 rack: Linear voltage amplifier for dynamic and precise motion.
SP75 rack: Switching power amplifier for fast motion.
These standard drivers can be equipped with controllers and sensor conditioners.
|
|
|
|
|
|
Piezo LEGS® - Electronics
As the Piezo LEGS® motor is a non-resonant motor, the drive electronics can be made very simple and reliable. There is no need to keep track of the temperature or other environmental factors normally associated with electronics for resonant piezo motors, nor is there a need to tune the motor for the surrounding mechanical structure, different cable lengths etc.
To drive the Piezo LEGS® motor you need four phases plus ground. To create motion in one drive leg of the motor element you need two phases, one for each side of the electrically separated halves of the leg. The walking drive principle of the motor requires two pairs of legs that operate independently, adding two drive phases.
The same curve form is used for all phases and normally with a drive voltage signal from 0 to + 48 V. For each drive leg the applied signals are normally phase shifted 90° between the two independent sides of one drive leg and normally 180° between the two pairs of legs (see figure to the left below).
It is our experience that most of our customers want to integrate the drive electronics into their own PCB boards etc. and we encourage this by having several design proposals available for different applications and demands. Please contact us if you need further information in this respect.
We also offer our own PDA 3.1 Driver. This is a low cost driver with a simple +/- 10 V analogue interface that allows you hook up the driver to any standard DC or servo motor controller.
There is also other commercially available drivers and controllers from different manufacturers that have been developed for the Piezo LEGS® motors and we would be glad to give you assistance.
|
|
PCI-compliant Low-Cost High Speed Line Driver Output Motion Controller
The new "SMC-4DL-PCI" and "SMC-8DL-PCI" are PCI-compliant motion controllers designed to meet user's high performance needs. These easy-to-use controllers are recommended for semiconductor manufacturing device, testing device and multiple axes robot like X-Y robot. Stepper and servo motor can be connected via motor driver unit. With the included driver of Windows version, users can easily build application software by using programming languages support Win32API function.
|
|
|
|
|
|
TMC-3D Multi-axis Motion Controller and Servo Drive
TMC-3D combines a multi-axis motion controller and a state-of-the-art digital servo drive functionality in a single compact unit. TMC-3D can control, via a CANbus, up to 8 Technosoft drives, including itself. Complex motion programs can be programmed using the high level Technosoft Motion Language (TML).
3D and 2 1/2D coordinated motion paths are executed through TMC-3D and 2 other Technosoft drives, using PVT commands (position, velocity and time). TMC-3D can be one of these drives that perform local 3rd order interpolation between PVT points. This unique combination offers a very cost effective solution for precise multi-axis applications, where 3D paths can be executed accurately using 2 drives and TMC-3D connected via CAN-bus.
Key Features:
- Multi-axis motion controller (up to 8 axes)
- Real-time 3D reference generator
- Powerful motion language commands including vector interpolation, 3D coordinated moves, G-code execution
- CAN network management
- Integrated servo drive for 1 axis, suitable for brushless / DC motors with encoder or resolver feedback
- Usable with all Technosoft drives
- Compact design: 136 x 95 x 26 mm
|
|
Offer of the month: 680 USD
Motion control never was that easy!
Include:
3 axis motion controller & PLC, color screen and Software.
The new PCM series from TRM are stand alone motion controllers with full PLC capabilities for up to 4 axes of servo control or stepper control. Applications can be programmed in TRM's MAP (Motion Application Programme) or 'C' language to give great flexibility for programmers.
Servo axes are controlled from the industry standard +/- 10 volts, from 1 up to 4 channels of DAC and encoder feedback are provided on the PMCx depending on the model.
Advantages:
- Easy to program
- Motion controller, PLC & HMI all in one
- Fast set up time
- Save time and money on software development
- Ideal for OEM's and end users
Typical Applications:
- XY Positioning Tables
- Conveyors
- Dosing
- Mixers
- Cutting machines
- Automatic Drills
- Postioners
- Bending Machines
- Wood Working Machines
- General Motion Control
- Robotics
|
|
New 3 Axis motion controller, 5.7" LCD screen and QWERTY Keypad
Price: GBP 700.00
(For OEM's and machine integrators discounts apply)
* 3 stepper axis
* 2 Servo axis control (+/-10V analogue outputs)
* 5.7" colour TFT display large text and animated machine functions
* 16 Digital Inputs and 16 Digital outputs
* 8 Analogue Inputs
* 2 Fast registration inputs (40 nS)
* Ports RS232, RS485, USB
* Linear and circular interpolation
* Electronic Cam, Synchronization, Virtual axis
* QWERTY key keypad
* Preloaded with Motion Application Software 'MAP'
|
|
New 3 Axis motion controller, 5.7" LCD screen and Keypad
Price: GBP 645.00
(For OEM's and machine integrators discounts apply)
* 3 stepper axis
* 2 Servo axis control (+/-10V analogue outputs)
* 5.7" colour TFT display large text and animated machine functions
* 16 Digital Inputs and 16 Digital outputs
* 8 Analogue Inputs
* 2 Fast registration inputs (40 nS)
* Ports RS232, RS485, USB
* Linear and circular interpolation
* Electronic Cam, Synchronization, Virtual axis
* 30 key keypad
* Preloaded with Motion Application Software 'MAP'
|
|
The new PCM series from TRM are stand alone motion controllers with full PLC capabilities for up to 4 axes of servo control or stepper control. Applications can be programmed in TRM's MAP (Motion Application Programme) or 'C' language to give great flexibility for programmers.
Servo axes are controlled from the industry standard +/- 10 volts, from 1 up to 4 channels of DAC and encoder feedback are provided on the PMCx depending on the model.
Advantages:
- Easy to program
- Motion controller, PLC & HMI all in one
- Fast set up time
- Save time and money on software development
- Ideal for OEM's and end users
Typical Applications:
- Positioning stages
- Linear modules
- Conveyors
- Dosing
- Mixers
- Cutting machines
- Automatic Drills
- Postioners
- Bending Machines
- Wood Working Machines
- General Motion Control
- Robotics
|
|
|
The DMC-1417 for the PCI bus is a member of the Econo Series, Galil's family of single-axis motion controllers which are half the size and half the price of multi-axis controllers. The DMC-1417 can handle the most demanding applications with such features as an extra encoder input for electronic gearing, program memory with multitasking, uncommitted I/O and user-selectable stepper or servo motor control. Modes of motion include point-to-point positioning, jogging, contouring, electronic gearing and ecam. Programming the DMC-1417 is simplified with two-letter, intuitive commands and a full set of software tools such as WSDK for servo tuning and analysis, ActiveX Tool Kit for Visual Basic users and a C-Programmers Tool Kit. The Econo Series controllers do not include uncommitted analog inputs and are not optoisolated. Use the DMC-1810 Optima controller if you require these features.
|
|
|
|
|
|
All synchronization controllers shown on this site operate according to the Master- Slave principle. Where the Master can freely move with any motion profile under control of any remote speed reference, the synchronizer will control one or several Slaves to exactly follow the Master motion in terms of position and speed.
The control is based on incremental position feedback by means of encoders on both sides. Many applications just use a measuring wheel with encoder instead of a Master drive. It is possible to preset every speed or gear ratio by means of adjustable impulse scaling factors.
All units can accept marker pulses from the encoders and from remote proximity switches or photocells, to automatically produce the correct position with pitch or cycle related applications. motrona synchronous controllers can operate with any kind of speed variable drives (AC- inverter, DC, Servo or hydraulic type) that follow to a +/-10V speed reference signal. The extremely fast position control loop provides excellent performance even with highly dynamic applications
|
|
The M3000 is Moog's answer to advanced digital high performance control for hydraulic and electric products. It includes the hardware called Moog's Servo Controller (MSC), software known as Moog Axis Control Software (MACS) and numerous extension modules. Our solutions often involve this controller and a variety of Moog products such as Servovalves, Servo-Proportional Valves, Servodrives and RKP Pumps.
This system of hardware, software, and extension modules offers rapid implementation and set-up to save time and money. As it is based on universal standards and a modular structure it is flexible and easy to implement.
The MSC is a high performance servo controller with PLC functionality capable of handling complex multi-axis functions and enabling cycle times as fast as 500 microseconds
|
|
Aerotech motion controllers are used in our own positioning systems and in motion control and positioning systems throughout the world. Products include the Automation 3200 intelligent, 32-axis motion, vision, PLC, robotics, and I/O platform that provides from 1 to 32 axes of synchronized control, the Ensemble stand-alone controller for up to 10 axes, and the Soloist single-axis controller family. In addition, Aerotech manufactures a complete line of drives that are perfectly matched to our motion controllers, as well as our brushless linear motors and brush and brushless rotary motors.
|
|
|
The Brick Motion Controller features 4 or 8 (optional) axes of analog +/-10V filtered PWM (12-bit resolution) or pulse and direction outputs. Standard I/O capability is 16 inputs and 8 outputs at 12-24V fully protected and isolated with separate commons for each bank of 8 inputs. Outputs are rated for 1 ampere each and are thermal-fuse protected. Outputs can be current sinking or sourcing depending on use of common emitter or common collector connections. Feedback with quadrature incremental encoders is standard.
|
|
With meticulous engineering and advanced electronics, our CompletePower™ speed controls and servo drives offer unprecedented reliability and precision servo motion control. From precision medical dosing systems to the rugged performance of industrial automation systems, our CompletePower devices can handle a wide variety of applications.
We have several versions of our CompletePower motion control products to meet your diverse application requirements. Drive performance includes simple 2-quadrant speed control to full 4-quadrant servo control with both encoder feedback and tachometer feedback options available. CompletePower drives operate from 11 to 70V with continuous currents from 8 to 30 Amps.
Not sure if one of our CompletePower drives will fit your application? Our expert team of engineers are here to help you with every aspect of your product design.
Contact us today and let us help power your innovation.
|
|
PLC, motion controller and DeviceNet - Profibus - ModBus - CANopen gateway
The quite new concept GWC unit provides three main functionalities: programmable logic controller (PLC), motion controller and gateway. As PLC and motion controller it permits the user to locally controll a process through fieldbus, serial links and I/Os and executing an user defined program. Working as bus gateway it allows the data exchanging among various automation field busses: CANOpen, DeviceNet ProfiBus, ModeBus working. The three functionalities, built in the same unit, allow an easy solution to a spread range of industry automation processes...
|
|
Pilz Motion Control (PMC) represents a flexible, modular and expandable automation system for complex motion and control functions. This automation system manages all the movements of a large number of physically separate servo axes within a plant. PMC provides an overall solution for automating your machine, from operation via the controller through to the movement of highly dynamic drives, including all safety aspects.
Universal IEC61131 programming within one project, covering PLC functionality to motion control, provides the basis for quick, easy implementation of every task. So functionalities such as electrical main shaft, cam mechanism, interpolation and camshaft are covered, as are all aspects of the motor drive technology. With many years of experience from numerous applications and industries such as packaging technology, and with innovative engineering, Pilz Motion Control provides the right solution for every requirement.
|
|
|
The Schneider Electric Motion motion controllers feature a uniform programming language and simple commissioning for easy application. They allow you to implement simple stand-alone solutions as well as to automate complex production processes. The integrated PLC and motion functionality of all motion controllers can be programmed as required with CoDeSys. Standard libraries with function blocks according to PLCopen ensure simple application. Commissioning is just as easy. EDS files are used for bus configuration of the CANopen participants. The TLM and LMC motion controllers also feature CoDeSys SoftMotion. This comprises multi-axis functions for cam disc, electronic gear and phase shift between master and slave, as well as NC interpolation.
|
|
|
Motion controllers are to generate the pulse signal to control the step motors and drivers and Autonics PMC Series is the controller, which operates and controls step & servo system.
|
|
The RMC70 product complements Delta's flagship RMC100 family and expands Delta markets by offering even more value for one and two axis applications. The following is a list of the currently available features. More options will be available in future releases.
RMC70 Hardware:
The RMC70 is a modular controller. The Base module - consisting of the CPU and the Axis module - is factory-configured. Each factory-installed Axis module is available with one or two control axis interfaces. Up to 4 expansion modules may be added to the RMC70, including digital I/O, analog reference and pressure or force inputs.
|
|
Whether you need motion control that is fully integrated with your control and information systems or an easy to use component solution, you've come to the right place. Allen-Bradley leads the way with cost-effective, world-class motion solutions that address your application needs.
If you require a solution that ranges from the shop floor to the top floor, Kinetix Integrated Motion is unbeatable. This fully-integrated solution combines architecture, world class Allen-Bradley motion products and motion application expertise that provides everything you need to achieve a competitive edge.
If you're looking for a simple yet powerful motion solution, you can benefit from our motion components that are designed to work in a wide variety of machine architectures. Allen-Bradley Ultra5000 Intelligent Positioning Drive and Ultra3000 Servo Drive with Indexing are designed to provide high performance motion control in a small package. Both are available with a DeviceNet option.
|
|
|
|
|
|
The PS 90 is a modular designed position control for maximal nine axes, divided in three groups, each with three axes. Because of this special feature, it is possible to operate respectively three 2-phase step motors or DC servo motors (brush and brushless). Each axis has two inputs for incremental encoder or position measuring system. Thus, very precise positioning in closed loop mode is possible for all drive systems. Step motors can be operated from full step up to 256 micro steps per full step. The PS 90 can be operated by a handheld terminal or a PC via the integrated USB interface. Point-to-point positioning mode with different velocity profi les as well as complex continuous-path control like circular interpolation or 3-axes linear interpolation are possible. Because of safety requirements, an external emergency stop button is pluggable.
The software tool OWISoft is also part of the delivery. Thus, the PS 90 can be configured and operated comfortably.
Please order the required drive modules directly with the base unit.
- up to 9 axes controllable
- for 2-phase step motors und DC-servo motors
- serial interfaces, USB 2.0
- 4 (8) TTL, 4 (8) analog and SPS inputs
- 4 configurable limit switch inputs per axis
- 4 (8) TTL, 4 (8) analog and SPS outputs
- point-to-point operation, circular + linear interpolation
- programmable velocity profiles
Option
- Ethernet and different field bus interfaces
- operation of brushless DC servo motors
|
|
|
|
