SCHMIDT® ServoPresses 405 to 460
- suited for forces from 15 N to 150 000 N
- free positioning accuracy of 0.01 mm (with full speed under changing loads)
- variable drive profiles
- simultaneous force and distance close loop control
- patented compensation of dynamic bending effects in real time
- real time process monitoring and quality evaluation
- robust and precise mechanical design
- operator safety by dual channel integrated safety circuits
Machine and process safety
- automatic lubrication
- forced cooling
- built-in mechanical clutch for increased reliability.
Cost effective assembly often requires using parts with significant
tolerances. The goal is to automatically compensate these part
tolerances to create precision sub-assemblies.
The SCHMIDT® ServoPress range is a synonym for such intelligent
assembly processes. The ServoPress modules are available for automatic
assembly lines as well as stand alone working cells, EC type approved.
|
|
The individual Single Workstation is a stand-alone unit with an integrated Assembly Press. It is characterised by its modular design that allows for flexible handling. The Assembly Press is configured, parameterized and controlled by a standard PC on MS Windows basis. The PC stores numerous programs that can be selected and changed very quickly. An integrated force-distance monitoring assures optimal quality for every part assembled.
Due to the numeric control no mechanic blocks are needed and no control valves have to be adjusted. A loaded program is used by the unit for precise movements. Operational safety is assured by category 4 safety installations around the assembly area. Optional increments are possible if required.
The work stations is suitable for precise and flexible pressing, jointing and shaping for a broad area of applications.
|
|
