• Temperature range: 20 to 1200°C (several models)
• Real-time thermal imaging, scan speed up to 48Hz
• 256 measurement points per line
• Wide choice of spectral and temperature ranges
• High-quality brushless motor (MTBF 40000 h)
• Three user-configurable 4-20 mA outputs
• RS485/RS232 digital communications (up to 1000 m)
• PC independent alarm output
• Rugged, waterproof IP65 enclosure
• Air purge keeps window free of dirt and condensation
• Water cooling for ambient temperatures up to 180°C
|
|
SKF Advanced thermal imager TMTI 2
Comprehensive high resolution thermal imaging package
The advanced thermal imager TMTI 2 is a user-friendly thermal imager, producing high quality images from invisible infrared radiation. The high resolution (160x120 /19 200 pixels) images are displayed on a large backlit 3½” screen, for ease of viewing. Powerful PC and report-writing software is supplied as standard, which help enable the user to perform comprehensive data analysis and enhancement of the images.
Advanced temperature measurement features are built-in to the TMTI 2 such as, automatic hot spot and cold spot finder, Maximum/Minimum temperature view of an area and temperature difference display of two user defined spots.
-Compact ergonomic design and light weight
-Non-contact measurement technique enabling measurements to be made safely on running equipment
-Wide temperature measurement range from –10 °C to 250 °C
-User selectable emissivity correction from 0,2 to 1,0 with reflective ambient temperature correction
-Laser pointer pinpoints the area of interest
-4 different selectable colour pallets
-20° x 15° field of view easily enables the application to be seen
-Large thermal image storage capacity, up to 1 000 images on SD card provided
|
|
The IRI 4030 is an innovative thermal imager product, which offers outstanding imaging and temperature measurement performance together with the traditional Irisys features of flexibility, ease of use, and minimal cost of ownership.
Irisys has produced an imager that is ideal for the thermographer and maintenance engineer alike; high quality images may be captured and manipulated offline or problems can be resolved on the spot. The camera comes with an industry leading 31/2" display and delivers price and performance that are unique to Irisys.
The IRI 4030 is especially suitable for use where high temperature measurement is required, such as in the petro-chemical, glass, cement, metal and refractory industries.
|
|
COOLSCAN 20 is a unique 2-dimension scan thermal imager with exceptionally large field of view (70°x180°).
The extended temperature measurement range (200°C to 1600°C) makes it suitable for various industries such as cement where it is used for controlling air flows of grate clinker coolers.
|
|
The IRI 1011 is a groundbreaking thermal imager product which brings the benefits of this versatile technology to the professional, the trades person
and the non-specialist alike.
The flexibility, ease of use and above all, the low cost of this product extend the normal application areas for thermal imaging from military and professional use, to wider use in industrial, commercial and domestic applications.
Typical applications for the IRI 1011 include:
Predictive and Preventative Maintenance
Process Monitoring
Research and Development
HVAC Troubleshooting
Vehicle Maintenance
General Industrial/Domestic
|
|
|
Infrared cameras PYROVIEW 380L compact mounted in weatherproof housings and in potential combination with pan-tilt-systems will enable you the continuous monitoring of outdoor areas, storages or production halls. The uncooled infrared cameras PYROVIEW will ensure long-term stability and a favourable system price.
|
|
For non-contact measuring and imaging of the temperature distribution on objects, IMPAC offers fixed thermal imagers.
These thermal imagers are designed for long-term use in industrial plants for process and quality control. Measuring a lot of different materials in temperature ranges between -40 and 3000°C the cameras are flexible tools. If required the units can be equipped with systems for lens purging and water-cooling.
Depending on the model, the imagers detect the surface temperature of an object with 76,800 or 307,200 pixels and achieve measurement rates between 30 and 60 frames per second.
For detailed information please see:
www.impacinfrared.com/EN/products/thermal-imaging/thermal-imaging.html
|
|
The narrow angle 9.1° x 6.8° lens enables detection and temperature measurement of small objects over long distances. The IRI 4040 is especially suitable for use in the power utilities industries for the inspection of substation and overhead distribution and transmission lines.
IRISYS has produced an imager that is ideal for the thermographer and maintenance engineer alike; high quality images may be captured and manipulated offline or problems can be resolved on the spot. The camera comes with an industry leading 3 ½" display and delivers price and performance that are unique to IRISYS.
The IRI 4040 is an innovative thermal imager product, which offers outstanding imaging and temperature measurement performance together with the traditional IRISYS features of flexibility, ease of use, and minimal cost of ownership.
|
|
The MobIR M3 and M4 are thermography cameras in cell-phone format which have been specially developed for troubleshooting in systems and at machines, as well as for construction thermography and for locating leaks.
These multitalented devices are equipped with a high resolution 2.2" color TFT display with an optical thermal image sensor. The thermal sensor is an uncooled microbolometer focal plane array (FPA) with a resolution of 160 x 120 pixels and a spectral range of 8 to 14 ìm.
|
|
FLIR i5 - A small infrared revolution
POINT, CLICK AND SEE THE HEAT
The FLIR i5 is the most compact, lightweight and easy-to-use infrared camera of its class that is currently available on the market.
All you have to do is just point and click to see the heat variations in the environment around you - and find exactly what you are looking for. No matter if you repair fuses, install windows, insulation or heating, ventilation or air conditioning systems.
See what you've been missing
The Infrared imagery is immediately and clearly visible on a full-colour display. You can save your readings as an image for later reference. The combination of advanced Infrared technology and modern digital imaging will make your building and maintenance inspections, as well as damage estimation, a lot easier.
CATCHING THE HEAT OF THE MOMENT
The FLIR i5 visualizes heat differences. Heat, or infrared radiation, is a part of the electromagnetic spectrum that is invisible to the human eye. Infrared radiation (IR) is emitted by every object above a temperature of -273°C. Every object - both living and inanimate - gives off heat as long as its temperature is above absolute zero or -273°C. That means even AC installations and ice cubes.
The human eye cannot detect infrared radiation, but an infrared camera can. It can take pictures of objects to show the amount of heat they are emitting. Such pictures consist of a map of colors that show surface temperatures of the object.
An infrared camera is thus an invaluable diagnostic tool in a variety of industries and applications, as it can detect abnormally hot or cold areas or components. In other words, you can detect problems that are not normally visible with the naked eye.
Infrared at work
Infrared cameras help many industries, sectors, companies, institutions, technicians and workmen finding what they are looking for and solving their problems. Faults, leaks, damages - anything that emits differentiated heat signatures - and in all types of situations and environments.
Our Infrared cameras are ideal to:
- Detect hidden problems
- Assess damages
- Survey moisture and leaks
- Identify energy losses and poor insulation
- Find electrical faults and overheating
|
|
With the PYROVIEW compact DIAS Infrared GmbH offers you a compact fixed-mount infrared camera based on state-of-the-art uncooled microbolometer arrays with up to 384 × 288 pixels with a temperature measurement range from -20 °C to 500 °C and a spectral range of 8 µm to 14 µm.
Different lenses with different aperture angles, optional weather protective housing and the real time data transfer via Ethernet interface with up to 50 frames per second and optional stand alone operation without PC ensure an easy integration into your systems.
|
|
DIAS Infrared GmbH as a manufacturer of state-of-the-art infrared cameras offers you an innovative infrared measuring technique for contactless temperature measurement of temperature distributions. The uncooled infrared cameras PYROVIEW with a robust housing are excellently suitable for industrial use.
The newest microbolometer arrays with up to 384 x 288 pixels, different temperature measurement ranges of -20 °C to 1250 °C and spectral ranges 8 µm to 14 µm, 3 µm to 5 µm and 4.8 µm to 5.2 µm guarantee optimal customization to your measurement task.
|
|
Benefits
Very fast and complete measuring of the surface
Monitoring of rotating cylinders
Monitoring and control of non-continuous processes
Features
Customized solutions (Hard- and Software)
Simultaneous measuring with 256 detectors
Wide temperature range from 0 °C to 550 °C
Very fast response times from 250 Hz
Focusable lenses from 20 cm to infinite
Spatial resolution from 1.4 mm x 256 detectors
High accuracy (1.0 %) and long term stability
Chopped Radiation Method for highest temperature stability
|
|
PYROSCAN18 is a pyrometric camera particularly well suited for displaying the inside of a furnace as well as for measuring, in real time, the temperature of various points in the image, whatever the dust level in the furnace.
The system is widely used in industry for combustion process control.
|
|
Infrared Camera Modules
For Applications in Industry, Process Engineering, HVAC Environments or Security
IR-TCM 384
For express visualization or measurement of heat distribution patterns: The IR-TCM 384 OEM camera module makes temperatures from -40 °C to +2.000 °C visible to the human eye with a resolution of <70 mK. The module registers two-dimensional heat distributions in real time and with a resolution of 384 x 288 pixels.
The IR-TCM 384 provides long-time stability of a level that sets new standards in the IR camera business. Fitted with typically used interfaces and facilities for flexible integration into specific customer software, it can easily be integrated in a variety of OEM applications.
IR-TCM 640
Visualizing or measuring heat distributions with high precision: The IR-TCM 640 OEM camera module generates images in real time with a resolution from 640 x 480 pixels up to 1.2 megapixel . This makes the IR-TCM 640 the first ever high-resolution infrared camera module for commercial applications worldwide.
Via standardized interfaces such as IEEE1394 Firewire, S-/C-Video or RS232 the module can be easily integrated in a multiplicity of applications. It is notably applications in the machine vision or the security sector where the module’s image resolution, which is actually on a level with photo quality, yields significant benefits in detection jobs.
|
|
|
The MIDAS 320L is an extremely light-weight, high-performance handheld infrared camera. It measures the infrared radiation emitted by the target surface and converts this radiation into a two-dimensional image relating to the temperature distribution at the target surface. This temperature distribution can be viewed in full color or grey-scale on the TFT-LCD display or viewfinder. This radiometric camera is ergonomically designed and easy tu use for applications in maintenance, building thermography and developement.
|
|
Fluke Ti10/Ti25: Latest innovation in affordable thermal imaging
Put problems clearly in the picture
With the rugged and reliable Fluke Ti10/Ti25 Thermal Imagers, you get the advanced problem-finding capability of IR-Fusion® technology. They are a complete and easy-to-use thermal imaging solution for troubleshooting and maintenance of industrial and electrical equipment.
|
|
HT ITALIA launch new HT1016 and HT1160 handheld infrared really innovative thermal imager models for high performance, more flexibility and easy to use. Electrical installers, tradesperson, project developments person but also thermal or mechanical technician can using this new technologies in order to solve their maintenance problem and, in more cases, obtain a valid help on the troubleshooting and preventive analysis of problem. Both models are built with a wide 3½" LCD colour display and a laser pointer for a great accuracy during the use of meter. HT1160 model, thanks to a 160x120pxls better resolution, permits a really good visualization of each saved thermal image. With internal OSD function the selectable languages, the meter parameters setting and the analysis of measurement results are completely easy to use for the operator. The thermal pictures can be saved in external SD flash card fitted inside meters with a capacity up to 1000 pictures. The USB port permits to transfer the thermal pictures to PC also by using dedicated Windows software. Typical applications of HT1160 thermal imager are:
- Predictive and Preventative Maintenance
- Plumbing and Electrical
- Research and Development
- HVAC + refrigeration troubleshooting
- Vehicle Maintenance
- General Industrial/Domestic
|
|
The portable thermal imagers are high resolution infrared cameras for non-contact temperature measurement between -20 and 250°C (IVN 770-P) respectively between -20 and 900°C (IVN 320-P). Their lightweight compact design makes them ideally suited for mobile applications.
The cameras can be used for numerous applications such as building inspection, predictive maintenance and process monitoring.
The IVN 770-P offers today the best price/value ratio for a 320 x 240 pixel camera.
For detailed information please see:
www.impacinfrared.com/EN/products/thermal-imaging/hotspot.html
|
|
|
The new VarioCAM® high resolution delivers thermal images offering the precice detail resolution you require for demanding applications in industrial research & development. With an image resolution of up to 1.2 megapixel, enabled by Jenoptik's worldwide unique Resolution-Enhancement-Technology, the camera sets new benchmarks in handheld mobile and stationary real-time thermography. VarioCAM®'s high thermal accuracy as well as long-term performance round off the versatile IR camera.
|
|
This full featured, high performance thermal imaging camera has a temperature measurement range from -20 to 1500°C/-4 to 2732°F and a high quality aspherical lens with motorised focus and digital zoom.
Thermal images are displayed in the viewfinder and bright LCD display. They can be displayed and captured for later use in reports.
Images and sound files are saved on to a Compact Flash memory card for download and further analysis.
The right camera for predictive maintenance and production processes. Detect the symptom before the problem occurs. High resolution image quality helps you quickly find the problem.
The Cyclops TI 814 thermal imaging camera is complemented by the Land Image Processing Software - LIPS, which provides thermal and visual image manipulation and storage together with report writing facilities.
LIPS is easy to use, highly flexible, and greatly enhances the versatility of the Cyclops TI 814.
The Cyclops TI 814 imaging camera is used in plant condition monitoring, structural integrity inspection, quality control, and research and development in industries such as: Power generation, transmission and distribution; Electrical and electronics; Energy management and thermal surveys; Steel and glass; Petrochemical and plastics; Construction and civil engineering.
|
|
|
Please note, that in Great Britain the infrared cameras are available via the company FLIR Systems, only.
|
|
The starter instrument for fast fault-finding and quality assurance
· High-quality wide angle lens 32° x 24° with F1 optics
· Image refresh rate 9 Hz
· Detector 160 x 120
· NETD < 0.1°C
· Manual focus
· Minimum focus distance 10 cm
· Data storage device SD, 1 GB (approx. 800-1.000 images)
Included in delivery
· IR software with integrated report creation
· USB cable
· Li-ion battery
· High-quality, robust case
|
|
|
The established infrared camera series PYROVIEW has been extended by DIAS Infrared GmbH with the new high temperature camera PYROVIEW 640 using a spectral range in the near infrared region. A continuous temperature measurement range from 600°C up to 1500°C is realised with a resolution of 640x480 points and a measuring frequency of 25Hz. Digital data transmission is made via a Fast Ethernet interface. The size of the compact housing is app. 60 x 60 x 160mm³.
|
|
|
The product line VarioCAM® high resolution of the German manufacturer JENOPTIK Laser, Optik, Systeme GmbH stands for a new generation of high-performance thermographic cameras based on state-of-the-art uncooled microbolometer FPA detectors with up to 1,280 x 960 infrared pixels.
|
|
The VIGOcam v50 camera is designed for temperature distribution measurements and recording in technological device diagnostic. It can be used in various scientific and industrial applications, eg. industrial process control, power and building industry, medical diagnostic and scientific research.
The camera is constructed with the use of a 384 x 288 microbolometric detector array. The new generation, 35 μm pixel, detector array and excellent optics ensure high thermal sensitivity (NETD: 0.08°C @ 30°C) and spatial resolution (1 mrad) of the camera.
The VIGOcam v50 camera is equipped with 3.5" LCD display, video camera, laser pointer, radio link that enables remote control, SD memory card reader, microphone and loudspeaker. Connection with a PC computer is possible via USB or Ethernet port.
The data sent to a PC computer can be processed with sophisticated THERM v50 software which offers various analytical functions to process temperature distribution data including charts, histograms within user-defined regions and report generator. The camera and it's software could be easily adjusted to the customer's specific requirements.
|
|
Fluke TiR Thermal Imager
Optimized for building envelope, restoration and remediation, inspection and roofing applications.
The Fluke TiR Thermal Imaging cameras are the perfect imagers for building envelope, restoration and remediation, inspection and roofing applications.
IR-Fusion® Technology
See things both ways—infrared and visual (visible light) images fused together communicating critical information faster and easier—traditional infrared images are no longer enough. IR-Fusion, a patent-pending technology that simultaneously captures a digital photo in addition to the infrared image and fuses it together taking the mystery out of IR image analysis. IR-Fusion is standard on TiR models.
|
|
|
