Operator interfaces - Human system interfaces
FEATURES:
Many Supplier of plcs supported
Friendly multiple languages supported to the end users
Temperature controllers suppliers & inverters directly connected to INDUSTRIAL HMI via Modbus
Data logging, bargraphs, trends and alarms
Animation: display/hide, flash, color changed
Data entry and data displayfrom/to PLC registers directly
Free configuration professional software, configuration for all HMIs from PC software
Upto 65535 professional screens in each project, pop-up screen and associated screen supported
Ladder programming (Soft PLC) supported in HMI and Ladder online monitoring
Screen security
Floating point suppored
Ready made registers for Real Time Clock
Unique Tag database for HMI and PLC registers
256 real time alarms, and 30 or 2000 historical alarms
Global tasks, power-on tasks, list of predefined tasks and screen tasks-before, while and after
Ready made objects for lamps, botton , data entry, data display, trend, alarm, bitmaps, meters
Action for graphical objects from list of predefined tasks
Ready-made system coils for changing REALTIME CLOCK data by sec., min., hour, day, month, year |
|
Beijer Electronics H-series H-T50b, touchscreen panel with mono STN LCD 4.7” display
Display: Mono STN LCD, 16 shades of blue
Presentation form: 4.7”(diagonal), 240 x 128 pxl
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need. |
|
Beijer Electronics EXTER T40/T40m, touchscreen panels with 3.5” display
Display: Graphic 64K color TFT/Graphic 16 grayscales
Presentation form: 3.5”, 320 x 240 pxl
USB Host
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
MT608TV2
Construction: plastic molding housing
Display:8" 640x480 65536 color TFT LCD
CPU and core logic: CIRRUS LOGIC® EP9315 200MHz
ARM920T core processor
DRAM: 64 MB on board
Storage: 32 MB flash memory on board,
1 CompactFlash™ card slot,
44-pin IDE interface.
I/O: 3 serial ports: Com1: RS-232/RS-485 2w/4w,
Com2: RS-232,
Com3: RS-232/RS-485 2w
1 Ethernet port (10/100Base-T)
3 USB 2.0 full-speed host (12Mbps)
Sound output: 20-bits Stereo output
RTC: Built-in
Power input: 24 VDC, 0.5A maximum
|
|
Visualization or visualization & control on a multifunctional platform
- Web, graphics and control panel
- Open platform allowing you to integrate your own professional software
- Based on Windows CE 4.2 (5.0)
- 4 digital I/Os on-board
- Control functionality
- Optional diagnostics and telecontrol (TSDiag+) |
|
- B/W or colour professional displays
- programmable and equipped with interface communication
- PMU and XGT series |
|
Operator panels of series AS-Pxx:
The devices allow for simple operation, diagnosis and monitoring of your machines and systems. You can design the user interface according to your requirements.
An intuitive operator prompting via touch monitor, assigned function
keys or a combination of both are possible. The use of insertable strips allows for individually labelling the keys.
Operator panels of series V606:
The convenient and cost-efficient operator panels for all systems,
which can be connected via modbus, are particularly suited for simple visualization tasks. In combination with our controllers, it provides you with a complete automation solution. |
|
Colors for your data
Industrial Operator Panel (INDUSTRIAL HMI) with 7.5" touchscreen color TFT display
64K colors TFT display
VGA (640x480 pixels) resolution
Resistive touchscreen
Connection to industrial bus systems and Ethernet (requires plug-in modules)
32 MB internal Flash memory
32 MB on removable media (option)
SSFDC memory card
IP65 front panel protection
Programmable with "Designer" professional software tool (option)
|
|
Beijer Electronics H-series H-T60b, touchscreen panels with mono/color STN LCD 5.7” display
Display: Mono STN LCD
Presentation form: 5.7” (diagonal), 320 x 240 pxl
Keypad: 1 Meny key and 5 user-defined function keys
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and professional touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need. |
|
G308 :
8.4" 256-color 640x480 TFT Display (G308A)
7.7" 256-color 640x480 DSTN Display (G308C)
3rd Generation INDUSTRIAL HMI from Red Lion
Configured using Crimson 2.0 Software (Must use Build 187 or later for G308A)
Powerful 32-bit ColdFire Processor
Configuration and Firmware are Stored in 8MB of Non-volatile FLASH Memory
Resistive Analog Touchscreen
Dedicated MENU Key and 6 Soft-Keys
Integrated Protocol Professional converter
Up to 5 RS-232/422/485 Serial Ports
10-Base-T/100-Base-TX Ethernet Port
Remote Web Access and Control Facility
USB Port for Configuration Download
Compact Flash Socket
UL Listed for use in Hazardous Locations. (See literature for class
and division details.)
NEMA 4X / IP66 Front Panel
24V DC Operation
|
|
Hardware
VGA 640x480 pixels, lighted, TFT colour graphics Industrial lcd display 10.4". (An enhanced TFT display is available as an option).
Resistive touch monitor.
Optional PS/2 professional keyboard / keypad interface.
Ethernet options available. Supports TCP/IP, ModbusTM and other protocols.
4 Mbytes of flash memory and 16 Mbytes RAM.
EIA-232, -422 or -485 serial interface. Additional serial ports available.
RISC 92 MHz MIPS R3000 processor.
The terminal is industrially hardened to operate in rugged environments and meets NEMA-4 specifications for washing, ice and salt spray.
Modular form factor also available.
Software/Firmware·
QlarityTM - Object-based programming language makes application design easy for non-programmers whilst also having the capability of highly complex applications.
Design with pre-defined objects, edit current objects or design new objects for your application
Windows® programming environment - Qlarity Industrial foundry is available for free.
Support for select partner hardware (distributed/remote I/O, motion control).
Keys around the display can be customised and your logo can be added to the legend. Custom hardware, firmware and software options are also available.
Contact us for a free trial demonstration terminal.
|
|
CIMO - monitor operator panels
There is a wide range of CIMO monitor operator panels
to suit every task and every budget.
CIMO monitor operator panel with LCD "TFT display"
Extremely slim design, outstanding colour brilliance,
excellent reading angle, front panel membrane-protected
against chemicals, new ergonomic design -
just a few of the impressive features of this top
product from Wöhrle.
CIMO operator panel with Windows CE - the latest
generation
This particularly high-quality range is the result of
the latest Wöhrle development and closes the gap
between text-oriented computer terminals and traditional
industrial Professional pcs. The operating system is
Microsoft Windows CE. This means that it is possible
to operate all standard applications and utilise the
advantages of this platform, such as the Internet
facility.
TFT LC professional displays are provided for the operating panels
of the future, providing high resolution and excellent
colour.
These ultra-compact operator panels are setting the
standard.
CIMO operator panel is the economical version
An easy-to-use membrane keyboard and a graphic
black and white LC display make sure that control
and monitoring is cost-effective. A particularly economical
solution.
CIMO monitor operator panel with CRT
This range of equipment with monochrome cathode
ray tubes provides the most innovative and economical
solutions in the field of operating and monitoring
plant and machinery. Protected at the front to IP 65
they also withstand harsh environments.a |
|
WOP-iT Web Operating Panel
HMI Panel with additional programmable logic.
From 3,5" to 19" one programming software for all panels: WOP-iT Designer. |
|
Beijer Electronics EXTER T70, touchscreen panel with TFT-LCD 6.5” color display
Display: Graphic 64K color TFT-LCD, resistive touch
Presentation form: 6.5”, 640 x 480 pxl
USB Host, USB Device and built in CF-card slot
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary. |
|
