Vibrating level limit switch VIBROCONT SCM-300
for liquidsWHGstainless steel

Add to favorites

Compare this product

Go to the ACS Control-System GmbH website for more information

Characteristics

Technology

vibrating

Medium

for liquids

Approvals

WHG

Material

stainless steel

Other characteristics

compact

Process temperature

Max.: 150 °C
(302 °F)

Min.: -40 °C
(-40 °F)

Process pressure

Max.: 40 bar
(580.15 psi)

Min.: -1 bar
(-14.5 psi)

Description

Vibrocont SCM-300 is a point level switch for liquids. The Vibrocont SCM-300 is designed for industrial applications in all industries, mainly the machinery industry. The Vibrocont SCM-300 is used for overfill prevention or pump dry-run protection in cleaning and filter systems as well as in cooling and lubrication vessels. Compact: – Smallest vibronic sensor Safe: – Continuous self-monitoring – Reliable switching independent of media properties Easy: – No calibration or adjustment – Plug & play Field of application Point level switch in compact design with stainless steel housing. Process connections: Threads Temperature: -40 to +150°C (-40 to +302°F) Pressure: -1 to +40bar (-14.5 to 580psi) Surface roughness: 3.2µm Approvals: WHG overfill prevention and leakage detection, CSA C/US, 3.1 material certificate, marine approval, final inspection report
