Wing nut L251CINpolyamidestainless steel
Add to favorites
Compare this product
Characteristics
- Types
- wing
- Material
- polyamide, stainless steel
- Nominal diameter
5 mm, 6 mm, 8 mm
(0.2 in, 0.24 in, 0.31 in)- Height
16 mm, 16.5 mm
(0.63 in, 0.65 in)- Width
33 mm, 48 mm
(1.3 in, 1.89 in)
Description
Materials:
Precision-cast stainless steel, (Aisi 304).
Surface:
Satin.
Colour:
Natural.
Inserts:
Stainless steel threaded stud (Aisi 304), (thread tolerance 6g).
Attention: the stud is mounted and glued in place.
SPECIAL REQUESTS:
It’s possible to supply the inserts with different lengths, on request and for quantities.
Upon request and for special quantities the wing nut can be supplied in AISI 316 stainless steel.
