Single-phase solid state relay
24 - 690 VAC, 35 - 125 A | S07 series
celduc relais
Random Solid State Relay designed for high inductive loads,
motors (AC-53) and phase angle control applications.
Back to back thyristors on output with TMS2 (*) technology for a
long lifetime expectancy : 12 to 275VAC 50A.
Voltage protection on input (transil) and output (RC+ VDR ) to have
a high immunity according IEC/EN61000-4-4 & IEC/EN61000-4-5
. Large plage de contr.le: 3 - 32VDC avec un courant de
commande r¨¦gul¨¦.
Large control range: 3-32VDC with input current limiter.
Green LED visualization on the input.
Designed in conformity with EN60947-4-3 (IEC947-4-3)
and EN60950/VDE0805 (Reinforced Insulation) -UL-cUL
IP20 protection by flaps on terminals.
