knurled knob / lobe / stainless steel
06194 norelem - Éléments standard mécaniques

{{requestButtons}}

Characteristics

  • Type:

    knurled

  • Configuration:

    lobe

  • Material:

    stainless steel

Description

Star grips stainless steel, similar to DIN 6336

Material:
Stainless steel 1.4308.
Grub screw stainless steel 1.4305.
Pin stainless steel 1.4310.

Version:
Ground and polished or blasted.
Grub screw and pin bright.

Drawing reference:
Form B: drilled through
Form C: blind hole
Form D: tapped and counterbored
Form E: tapped blind hole
Form L: external thread
