Globe valve 454 serieswith handwheelfemale-femalestainless steel
Add to favorites
Compare this product
Characteristics
- Type
- globe
- Operation
- with handwheel
- Body
- female-female, stainless steel, bronze, PTFE
- DN
Max.: 2 in
Min.: 0.25 in
- Pressure
25 bar
(362.6 psi)- Temperature
Max.: 180 °C
(356 °F)Min.: -10 °C
(14 °F)
Description
Useful for the 2nd group in the common liquid forms, this product has a minimum temperature of -10°C and 180°C maximum. It shows an arrow that indicates the flow of direction. It is also specified with a rotating stem and a hand wheel. It has a bronze body with a union hat and a PTFE packing. It also consists of a stainless steel disc with a threaded female cylindrical BSP.
SPECIFICATIONS :
• - Respect the flow direction ( mdicated by the arrow )
• - Rising rotating stem and handwheel
• - PTFE packmg
• - Bronze body with union bonnet
• - PTFE or stamless Steel dise
• - Threaded female BSP cylindncal
USE:
• - For common fluids of 2nc group
• - Min and max Température Ts : - 10°C to + 180°C
• - Max Pressure Ps : 25 bars ( see graph )
