Stroke : 50 mm - 6,000 mm
Speed: 2.5, 5 m/s
Series 5E axes are mechanical linear actuators in which the rotary movement generated by a motor is converted into a linear movement using a toothed belt or a recirculating ball screw. Series 5E, available ...

Stroke : 50 mm - 850 mm
Speed: 180 mm/s - 650 mm/s
Force: 43 N - 400 N
Electric linear guide with high rigidity and absolute encoder for AC and DC power supply EZS Series Features: Battery-free absolute sensor No external sensors required Low heat generation High stiffness EtherCAT, ...

Stroke : 50 mm - 850 mm
Speed: 150 mm/s - 800 mm/s
Force: 40 N - 500 N
Electric linear guide with absolute encoder for AC and DC power supply EAS Series Features: Battery-free absolute sensor No external sensors required Low heat generation EtherCAT, EtherNet/IP, Profinet, Modbus ...

Stroke : 800 mm
Speed: 16.76 mm/s - 166.62 mm/s
Force: 250 N - 2,000 N
Thomson compact linear systems address the need for thrust and bearing support in a single, small-scale unit for space-conscious applications. Whether you opt for one of our three standard architectures ...

Stroke : 11,000, 3,000 mm
Speed: 6.5, 10 m/s
Force: 150, 500, 700 N
WH40 (SPEEDLine) Linear Units SPEEDLine WH40 positioning slide is a miniaturized linear drive unit designed for extremely small and compact ...

Stroke : 2,000 mm
Speed: 3 m/s
Force: 100 N
WH40 (SPEEDLine) Linear Units SPEEDLine WH40 positioning slide is a miniaturized linear drive unit designed for extremely small and compact ...

Stroke : 3,700, 6,000, 9,000, 11,000 mm
Compact linear unit for polluted environment The Essential • Movement provided by a linear guide with recirculating caged balls and a toothed belt located inside ...
Rollon

Stroke : 1.7 m - 19.7 m
Speed: 1.6 m/s
... accuracy. The track motion offers the following standard features: Performance best in class Simple, robust and compact design - Many common modules for complete range - Easy to adjust at start ...

Stroke : 1 m - 21 m
Speed: 2 m/s
Modular platform design ABB’s Medium Track Motion (MTM)’s design is smart and compact with a symmetrical profile. Maximum integration ensures the protection of components in a small footprint. The ...

Stroke : 1.9 m - 19.9 m
Speed: 2 m/s
... path accuracy. The track motion offers the following standard features: Performance best in class Simple, robust and compact design - Many common modules for complete range - Easy to adjust at start ...

The KL 4000 linear unit is a linear axis for payloads of up to 4,000 kilograms. It consists of two modular beam elements measuring 1.5 and two meters in length. This ...

Stroke : 50 mm - 4,000 mm
Force: 57 N - 1,300 N
... High Thrust Micron Position Accuracy Built-in Double Rail Modular Linear Motor Stage for Cross Table or Gantry System Main Feature Thrust Range 57N – 1300N. Feedback control via linear encoder ...
Chengdu Fuyu Technology Co., Ltd

Stroke : 50 mm - 300 mm
Speed: 300 mm/s
Force: 3 kgf
... Technical Feature】 FSL30 Series are trapezoidal rods ball screw linear guides. With delicate design and strong practicability, FSL30 is the best choice for customers who require compact, light and micro ...
Chengdu Fuyu Technology Co., Ltd

Stroke : 50 mm - 1,000 mm
Speed: 40 mm/s - 250 mm/s
Force: 10 kgf - 25 kgf
Technical Feature FSK40 linear guide is semi-sealer structure, body width 40mm, high stability,compact structure,versatility feature, suitable for normal working environment, it is convenient to use ...
Chengdu Fuyu Technology Co., Ltd

Stroke : 0 mm - 5,677 mm
Speed: 0 m/s - 10 m/s
Force: 4,367 N
... conditions, we are supplementing our series of toothed belt driven linear axes of the type RK MonoLine with a completely corrosion-protected variant in the common size 80. The compact linear ...
RK Rose+Krieger GmbH

Stroke : 10 mm - 2,769 mm
Speed: 2 mm/min - 1,020 mm/min
Force: 500 N - 2,100 N
E-II-stainless: 100% corrosion-resistant single-tube linear units The E-II single-tube linear unit is an all-rounder for format adjustment. The E-II stainless steel ...
RK Rose+Krieger GmbH

Stroke : 50 mm - 2,250 mm
Force: 50 N - 2,400 N
Maximum flexibility EPX-II KG linear units easily put away medium and high loads and give the user a free choice when it comes to the installation position. They can be equipped with either a short ...
RK Rose+Krieger GmbH

Stroke : 25 mm - 1,740 mm
Speed: 0 m/s - 1.2 m/s
Spindle drives Maximum load Spindle drives combine large strokes with high precision at high strain. strokes up to 1700 mm load up to 5000 N speed up to 1,2 m/s up to +/- 0.003 mm repeat accuracy

Stroke : 3,000, 5,500 mm
Speed: 3, 5 m/s
Force: 300, 880, 1,240, 4,000 N
HM-B: The linear axis with toothed belt drive is a compact, flexible positioning module. It is specifically ideal for applications requiring high dynamic responses and speeds. In addition, ...
HIWIN GmbH

Stroke : 25 mm - 1,491 mm
Speed: 0 m/s - 1 m/s
KK: The linear axis with ballscrew and steel profile is a compact, flexible positioning module. It is ideal in particular for applications requiring high rolling moments around the axis.
HIWIN GmbH

Stroke : 52 mm - 801 mm
Speed: 0 m/s - 1 m/s
KF: Thanks to the four ball tracks and the additionally integrated SynchMotionTM technology, particularly smooth synchronous operation and very low noise development are achieved.
HIWIN GmbH

Stroke : 400 mm - 600 mm
Speed: 0.15, 0.5, 0.3 m/s
Force: 1,000, 900, 800 N
The ready-to-connect axis system SL4 consists of a linear axis with spindle drive and precisely matched drive components (servo motor and servo amplifier). Depending on the application ...
JAT - Jenaer Antriebstechnik GmbH

Stroke : 165 mm - 750 mm
Speed: 2 m/s
Force: 320 N
The ready-to-connect axis system ZL2 consists of a linear axis with a toothed belt drive and precisely matched drive components (servo motor and servo amplifier). It is especially suitable ...
JAT - Jenaer Antriebstechnik GmbH

Stroke : 100 mm - 1,500 mm
Speed: 2.5 m/s
Force: 570 N
The LA230 is a linear motor axis with an iron-core linear motor. Equipped with precisely matched drive components (servomotor and servo amplifier), the LA230 is predestined for linear ...
JAT - Jenaer Antriebstechnik GmbH

Stroke : 2,000 mm
Speed: max 1.0 m/s
Force: 100 N - 1,000 N
The NL guide system has been specially designed to allow light loads to be handled with a screw solution. Being compact, its application proves advantageous whenever the distance to be covered is quite small. The use ...

Stroke : 1,410, 1,325 mm
Force: 4,670, 9,390, 13,080, 18,800 N
CTV series are Linear Units with precision ball screw drive and two parallel integrated zero-clearance Ball rail guiding systems. Compact dimensions provide high load capacities, high ...
UNIMOTION

Stroke : 1,690, 1,590 mm
Force: 8,930, 17,870, 15,320, 30,680 N
CTV series are Linear Units with precision ball screw drive and two parallel integrated zero-clearance Ball rail guiding systems. Compact dimensions provide high load capacities, high ...
UNIMOTION

Stroke : 5,163, 5,224 mm
Speed: 0.3 m/s - 2.5 m/s
Force: 34,200 N
... describes Linear Units with précision bail screw drive, integrated guide rail and compact dimensions. They provide high performances features, such as high speeds, good accuracy and ...
UNIMOTION

Stroke : 60 mm - 5,260 mm
Speed: 2 m/s - 6.8 m/s
Force: 15 N - 3,200 N
... portal axis •Maximum stroke at minimum installation space •Cost-efficient entry into linear motor technology Portal axes PEL20 •Compact axis for higher masses •High ...

Stroke : 20, 100 mm
Speed: 0 m/s - 2.5 m/s
Force: 8 N
... lying on its side. The linear axis is designed for small to medium-sized strokes with loads up to 30 N. The hard-coated aluminum slide is dynamically driven by a Tecnotion ...
Eitzenberger Luftlagertechnik GmbH

Stroke : 20, 60, 200 mm
Speed: 0 m/s - 2 m/s
Force: 45 N
Compact design, high load capacity and very high positioning accuracy are the outstanding features of the linear axis EZ-2352-094. The air bearing axis is designed for ...
Eitzenberger Luftlagertechnik GmbH

Stroke : 150, 250, 350 mm
Speed: 0 m/s - 2 m/s
Force: 66 N
The EZ-2542 Linear Axis is designed for loads of up to 200 N. A key feature of the axis is the angular arrangement of the air-bearing surfaces, which enables the very compact ...
Eitzenberger Luftlagertechnik GmbH

Speed: 8 m/s
Force: 600 N - 13,860 N
Mechanical linear unit with two internal rail guides for higher moments. The system is driven by an integrated linear motor.

Stroke : 50, 25 mm
Speed: 30 mm/s
Force: 45 N
... horizontal and vertical applications This compact and robust linear axis is easy to integrate and is characterized by an optimum price-performance ratio together ...

Stroke : 0 mm - 2,740 mm
HDCS (Heavy Duty Compact Screw) is based upon the HDCB compact beam with single edge V slides, and features ball screw actuation. System lengths are available up to 2740mm with the 25mm ball screws. Standard ...

Speed: 4 m/s
Force: 65 N - 180 N
The HL series is a linear motor axis that incorporates tight and accurate recirculating ball bearings. The model also has an absolute gauging system, and a mechanized lubrication system. It has a rated ...

Stroke : 400, 300 mm
Speed: 9 mm/s
Force: 1,250 N
The housing of the linear units SLA and SLG are made out of colorless anodized aluminium profiles with dimensions 35x35 mm (SLA) or 45x45 mm (SLG). Up to 8 linear units ...

Stroke : 300, 450 mm
Speed: 4 m/s
Force: 180, 380 N
... installation The HL linear motor axis provides the most modern drive technology – highly integrated and ready for installation. It allows flexible use and can be installed horizontally or vertically ...

Stroke : 1,000 mm
Speed: 3 m/s
Force: 15,000, 50,000 kN
modular travel axis made of aluminum for small robots and cobots Especially designed for small robots in assembly and handling applications Compact design thanks ...

Stroke : 3,000 mm - 30,000 mm
Speed: 1.5 m/s
Force: 0 N - 1,000 N
... Wire drum carrier stand - Robot base / raiser - With or without motor (indexing servo control or robot-synchronised servo axis)

Stroke : 100 mm - 300 mm
Force: 600 N
IMAO's Mechanical Linear Actuator can be used with simple manual adjustments without complex processes of parts selection, design and assembly. The internal parts are protected from dust by its aluminum profile body ...

Stroke : 100 mm - 300 mm
Force: 600 N
... 250 mm / 300 mm / 350 mm / 400 mm / 450 mm / 500 mm Allowable Load: 600 N Speed: Manual Operated Ready-to-use mechanical linear units! No parts selection, No designing & No assembly! Easy mounting by square aluminum ...

Mechanical Linear Actuators No Part Selection! No Designing! No Assembly! IMAO's pre-assembled Linear Unit can be used with simple manual adjustments without complex processes of parts ...

Stroke : 500 mm - 3,000 mm
7th axis for robots With the so-called 7th axis linear adjustment, the radius of action of robots is extended and thus they become much more flexible in their applications. Flexible ...
