In-line load cells

Rated force: 0.5 N - 5,000 N
Rated load: 5 lb - 50,000 lb
Height: 11.43 mm - 38.1 mm

Honeywell miniature load cells are designed to fit into systems with limited space or tight clearances. The Model 31 series are Honeywell's highest accuracy, rugged, miniature load cells designed to measure both tension and compression ...

Rated force: 10 N - 200 N

Accuracy Class: - 0.2 Range of Application: - Miniature Sensor, e.g. for Survey of Rope Force or Force Determination of a Bowden Wire Performance Features • Miniature sensor for tension force • Simple handling and assembly • Reliable ...

Rated force: 0.5 kN - 1,000 kN

Force sensor, small dimensions, IP67 0 ... 0.5 kN to 0 ... 1 000 kN • Force sensor • Small dimensions • Tension and compression • Protection level IP67 • Stainless steel

Rated force: 50 kN - 300 kN

2912 rod end in-line tension and compression force transducers are made of mild steel. These force sensors feature small azimuth angle error, which makes them ideal solutions for in-line applications. with its non-linearity of 0.1%fs ...

Rated load: 15,000 kg - 50,000 kg

The COK series is designed from an alloy steel construction, and has a protection level of IP 68. The unit provides a combined error of <+/- 0.02 %, and zero balance of +/- 1 %. The device functions in an operating temperature of -30° ...

Rated load: 10 t - 500 t

features Tension/compression load cell TYPE 112 can be used in high loading capacity weighing systems. Some applications are: Tensile stress measuring on trailers Traction measures on test machines Weighing on lifting ...

Rated force: 10, 2, 50, 20 kgf

The S300 Single Point Load Cell is low profile, bi-directional, and overload proof. With an integral overload stop for both tension and compression, this sensor's unique design allows it to be used as a platform load cell or as a tension/compression ...

Rated load: 100 kg - 1,000 kg

Features Tension and Compression load cells accuracy:0.05%R.O. super micro structure stainless steel construction environment protection class:IP65 Applications Press applications Weighing Sensing for applied load Automation ...

Rated load: 15 t - 60 t

Compression load cell, selfcentering column 4000 divisions O.I.M.L. R60 class C Simple to install Capacity: 15T-60T Stainless Steel construction Hermetically welded, protection class IP 68 (EN 60529) and IP 69K ...

Rated force: 10 N - 500 N

10,30,50,100,200,500N Inline load cell Product Description Brans’s miniature load cells/force sensors are designed to fit into systems with limited space or tight clearances. The Model 301 series are the miniature load cells designed ...

Rated force: 50 N - 1,000 N

Features & Applications  Miniature load cell，low profile，small deflection  Made of stainless steel  Tension and compression application  Mainly used for automotive press fit, automated assembly, 3C products testing, new energy ...

Rated load: 1,000 kg - 10,000 kg
Length: 125, 185 mm
Height: 29 mm - 31 mm

The ADK load cell has a capacity range from 1.000kg up to 10.000kg and 30mm maximum cable diameter. It is indicated for load limiting in gantry crane, tower cranes, lifts, elevator, forklifts, etc… TECHNICAL DATA Load cells designed ...

Rated load: 5,000 lb - 200,000 lb
Length: 180 cm

• Male to Female Thread Connection • Accuracy of 0.15% • Heavy-Duty Construction for High-Capacity Loads OMEGA’s LC704/714 Series tension links have a male to female thread connection; LC704 with a 1.8 m (6') cable, and LC714 with ...

Rated load: 900 kg - 90,000 kg

• Accuracy, ± 2% of full scale • Zinc and bronze plated to resist rust and corrosion • Dual-range readout in kilograms and pounds • Cushioned metal case provides safe storage and transport • Maximum indicating pointer reading for ...
