One-way clutches with internal bearings
Torque: 5.88 Nm - 980,000 Nm
... situation of commitment and disengagement are reiterated randomly, while the Cam Clutch outer and inner races use each other to send out torque, and while the Cam Clutch prolongs overrunning during the ...
Torque: 29 Nm - 260 Nm
... Compact Design The BB Series functions both as an one-way clutch and a bearing within its compact body, allowing you to use your space more effectively. 2. Easy Installation You ...
Torque: 113,400 Nm - 503,550 Nm
Diameter: 230 mm - 320 mm
Rotational speed: 110 rad.min-1 - 200 rad.min-1
Torque: 45 Nm - 160,000 Nm
Diameter: 12 mm - 300 mm
Rotational speed: 400 rpm - 5,500 rpm
... multitude of standardized bore diameters are available with short delivery times. Application as: - Backstop - Overrunning Clutch - Indexing Freewheel
Torque: 45 Nm - 5,000 Nm
Diameter: 12 mm - 75 mm
Rotational speed: 800 rpm - 5,500 rpm
Complete Freewheels FBS in stainless steel are sealed sprag freewheels with ball bearings. They are supplied oil-filled and ready for installation. In addition to the standard type, ...
Torque: 9 Nm - 420 Nm
Diameter: 12 mm - 40 mm
Rotational speed: 3,000 rpm - 10,000 rpm
Internal Freewheels FZ are sprag freewheels with bearing support and ball bearing properties. The freewheels are supplied grease-filled ...
Torque: 210 Nm - 27,500 Nm
Diameter: 0.5 in - 15 in
Rotational speed: 350 rpm - 3,600 rpm
The FR series by Ringspann is is full face one way clutch used for bolting the face in inch dimension with sprags. This is a sealed sprag freewheel in inch dimension ...
Torque: 55 Nm - 68,000 Nm
Diameter: 12 mm - 150 mm
... Features Complete Freewheel FGR R A1A2 with mounting flange are sealed roller freewheels with ball bearings. They are oil lubricated. The freewheels FGR R A1A2 ...
Torque: 373 Nm - 33,900 Nm
Diameter: 15 mm - 160 mm
Rotational speed: 0 rpm - 3,600 rpm
The M series is a high capacity freewheel clutch developed by Cross and Morse. It is built with high chrome alloy steel, hardened and honed ensuring accurate shape. The unit comes with unique finishing ...
Torque: 54 Nm - 597 Nm
Diameter: 50.8 mm - 114.3 mm
Rotational speed: 300 rpm - 1,800 rpm
PB Sprag Clutch PB Sprag Clutches feature precision formed sprags for maximum torque capacities combined with long life. The clutches have an outer race designed to simply attach sprockets, gears or pulleys with a plain ...
Torque: 53 Nm - 1,695 Nm
Diameter: 16.5 mm - 56 mm
Rotational speed: 2,500, 2,000, 1,800 rpm
... outside diameter is the same as 62 series ball bearing enabling simple fitting beyond the bearing on intermediate or output shafts of gearboxes. Bore sizes range from 16.5 mm to 56 mm for operation alongside ...
Torque: 53 Nm - 588 Nm
Diameter: 10 mm - 60 mm
COMPLETE FREEWHEEL CLUTCH UNITS GMN complete freewheel clutch units are particularly suited for high torque requirements. The FPD, FND, RA, FP and FN series are characterized ...
Torque: 53 Nm - 267 Nm
Diameter: 17 mm - 40 mm
... ball bearing freewheel clutch units without seals are suitable for either oil or grease lubrication. All GMN ball bearing freewheel clutch ...
... ball bearing technology, we were able to develop and design these one-way clutches with features such as a built-in clutch element integrated into a molded design. We ...
Torque: 55, 93, 130 Nm
Diameter: 62, 47, 52 mm
Rotational speed: 5,200, 4,200, 6,000 rpm
The CKN series is a freewheel incorporating a 62.. series bearing, self-centring, grease-lubricated and comes with water protection This model is equipped with a keyway on the inner race and should be ...
Torque: 20 Nm - 35,000 Nm
Diameter: 37 mm - 300 mm
Rotational speed: 250 rpm - 3,600 rpm
The GF Series freewheels are self centering. From size 8 to size 20, centering is steel on steel, while from size 25 to 130, centering is ensured by 2 160.. series bearings. Torque forces are transmitted ...
Torque: 55 Nm - 70,000 Nm
Diameter: 62 mm - 400 mm
Rotational speed: 200 rpm - 5,600 rpm
... be applied to the freewheels before operation, following instructions given on page 12. Each freewheel is supplied with two paper gaskets that must be inserted between the outer race and the flanges. ...
The SA Series clutch is a light duty product with plain bearings. Features Suitable for all small machine applications where compact dimensions are required Grease lubricated and sealed for ...
... series is manufactured Maedler, and is an idler that is made of special cast iron, which is integrated with one-sided flange with plain bearing. It has a payload capacity ranging from 400 to 2000, which ...
Diameter: 7.2 mm - 72 mm
The OWC-GXZ One Way Bearing Series is a line of compact, unidirectional clutches. It is made out of a sintered alloy outer ring, a stainless steel roller, a leaf spring, and a welded ...
Our molded thermoplastic idlers offer an economical solution to tail sprockets. They are specifically engineered to spin freely on the shaft and work with Rex® chains to ensure long life and high productivity.
Torque: 0 Nm - 156,000 Nm
Diameter: 180 mm - 300 mm
Rotational speed: 70 rpm - 1,300 rpm
The RSCI 20-130 series by Stieber is a Backstop clutch which comes with an inner race rotating. This tool is ideal for freewheeling. The bearing must be provided in an operation to ensure ...
