Pilot valves

DN: 15 mm - 150 mm
Pressure: 3, 16 bar
Temperature: 220 °C

High precision pressure reducing valve with motorized actuator for remote operation (with built-in separator and trap) Benefits and Features Easy to Use A motorized actuator is mounted on the pressure reducing ...

DN: 3 mm
Pressure: 35 MPa
Temperature: -15 °C - 60 °C

... These valves have garnered an excellent reputation since their launch by Yuken in 2001. Direct type LSVG-03 and two stage type LSVHG-04/06/10(which use the LSVG-03 as a pilot) are available. Cetop 5 ...

Pressure: 250 bar
Flow rate: 120 l/min

... options and types available. The valve has two pump inlets and two tank outlets which allow the plumbing to be connected either from the side or top of the valve. It also features a full flow pilot ...

DN: 40 mm - 80 mm
Pressure: 0.5 bar - 10 bar

The BERMAD Top Pilot Pressure Reducing Control valves offer top performance, compact design, and intuitive plug-and-play operation, thanks to an innovative integrated pilot, equipped ...

DN: 80, 100 mm
Pressure: 0.2 MPa - 0.6 MPa
Temperature: -25 °C - 55 °C

Through the pilot dividing into one action, the exhaust passage I on the pilot part 1 is connected with the passage II on the cover 2. The compressed air of the upper chamber III of the diaphragm 3 is ...

The actuator pilots of the OS Series are especially designed for pressure control in regulators and shutoff valves, they can operate on maximum and minimum pressure, on maximum only, on minimum only.

DN: 25.4 mm
Pressure: 206.8, 103.4, 482.6 bar
Temperature: -54 °C - 204 °C

The UPCV10-F41 is a screw in, cartridge style, internally piloted, pilot unloading valve with an internal check valve with fixed reload pressure ratio of 80% for use in accumulator type ...

... operated pilot-controlled. modulating valve. It is designed to maintain a constant pressure differenlial between any two pressure points ina System where the closing of the valve directly ...

DN: 50 mm - 300 mm
Pressure: 16 MPa
Temperature: 0 °C - 60 °C

Pilot operated Ductile Iron Pressure Reducing Valve Additional information Material - Ductile Iron Typology - Dynamic balancing Connection - Flanged Ductile Iron pressure reducing valve Max ...

Pressure: 10,000 psi
Temperature: 0 °C - 49 °C

... Model DV Series Dump Valve is a pneumatically-operated control valve for instantly releasing the flow of liquids under pressure in a hydrostatic pressure system. Designed for operator safety and to reduce ...

DN: 32 mm - 1,000 mm
Pressure: 10 bar - 40 bar

K3 HYDROSTAB LEVEL Control valve HYDROSTAB LEVEL offers different possibilities to control the level, constant or not, with the altitude pilot or float pilot. The wide range of altitude ...

DN: 50 mm - 600 mm
Pressure: 1.6, 2.5, 4 bar

Pressure Relief Valve Body: Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel Diaphragm: EPDM , NBR Disc: Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel Pilot Valve: ...

DN: 1.411 mm
Pressure: 50 psi - 25,000 psi

... These valves perform a function similar to a pressure switch. The sensing piston or plunger movement is spring or air adjusted. When the sensed pressure is reached, a small, integral air valve shifts ...

DN: 16 mm - 160 mm
Pressure: 350 bar

Hydrodynamic distributor for 3/3 valve with pilot oil Working pressure of 350 bar. Min. DN16 Max. Dn160 TECH-Euroengineering designs and builds any hydrodynamic distributors (water) for forging ...

DN: 40 mm - 900 mm

PILOT OPERATED FLOAT VALVE - Same construction as Model C000/CF000. For level control of storage tanks, reservoirs, or basins. CONSULT FACTORY for control valve price list for specific options.

Pressure: 320 bar

Pressure reducing stackable valves Cetop3, pilot control, available with controlled flow on B-P lines. Max. working pressure 320 Bar

Pressure: 210, 315 bar
Flow rate: 57, 85 l/min

... tries to run ahead of pump, pilot pressure will decrease and the relief section will throttle or close to prevent runaway. The T port is also useful in cylinder applications where directional valves (specifically ...

Pressure: 0 psi - 125 psi
Temperature: -20 °F - 180 °F

Any TAC Push Button Valve may be operated with a choice of four TAC Air Pilot Operators. Valves are miniature 2, 3 and 4-way, and available in 10-32 UNF, 1/8 and 1/4 pipe sizes. Thread ...

Pressure: 500 bar
Flow rate: 15 l/min

... 51 519). The check valves without pilot control feature a ball as a valve element. The valve version with pilot control contains a spherical grinded ...

Pressure: 5,800 psi

Dual Pilot Operated Check Valves/Dual Safety Circuits dual safety circuits zero leak check valves The block splits incoming clamp line into two circuits. This provides dual safety ...
