Maximum supported speed: 120 km/h
... The bogie is developed for the operation in the UK. The bogie frame is fabricated without front and back transverse beams. The brake is simple, asymmetric, suitable for as called “push” brake. The bogie ...
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 120 km/h
Bogie mass: 4.5 t
... The two-axle bogie of a standard construction is intended for railway freight wagons and is designed to satisfy all requirements of railway freight transport. The bogie complies with the European legislation ...
NYMWAG CS a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 120 km/h
Bogie mass: 4.4 t
... The two-axle bogie of a standard construction is intended for railway freight wagons and is designed to satisfy all requirements of railway freight transport. The bogie complies with the European legislation ...
NYMWAG CS a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 120 km/h
Bogie mass: 4.1 t
... The two-axle bogie with an H-shaped frame is designed for railway freight wagons to satisfy all requirements of railway freight transport. The bogie complies with the European legislation TSI WAG, ...
NYMWAG CS a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 120 km/h
Bogie mass: 4.1 t
... The two-axle bogie with an H-shaped frame and an integrated brake is designed for railway freight wagons to satisfy all requirements of railway freight transport. The bogie complies with the European ...
NYMWAG CS a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 100, 120 km/h
Bogie mass: 7.8 t
... - 2 x 1 700 mm Maximum bogie speed at empty wagon - 120 km/h Axle pin diameter - 130 mm Axle pin length - 191 mm Distance between axle pin centres - 2 000 mm Height of the bogie pivot center above ...
Tatravagónka a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 120, 100 km/h
Bogie mass: 4.9 t
... properties of the headstock-free bogie are identical with the standard Y25Ls1-K bogie. Removal of the headstock preserved similar strength and running characteristics, but it also caused lower weight of the frame and ...
Tatravagónka a.s.
Load capacity (tons/axle): 20, 22.5 t
Maximum supported speed: 100, 120 km/h
Bogie mass: 4.8 t - 4.9 t
... Height of the bogie pivot center above the top of rail at a wagon tare of 20 t - 925 mm (+3/–5 mm) Specific bogie suspension for the axle load - 6.63 t (0.93 mm/t) Bogie brake rigging ...
Tatravagónka a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 100, 120 km/h
Bogie mass: 4.6 t
... Gauge - 1 435 mm Height of the bogie pivot center above the top of rail at a wagon tare of 20 t - 925 mm (+3/–5 mm) Specific bogie suspension for the axle load - up to 6.63 t (2.45 mm/t) | over 6.63 ...
Tatravagónka a.s.
Maximum supported speed: 100, 120 km/h
Bogie mass: 4.5 t
Wheelbase: 1,800 mm
... Length - 3 250 mm Height of the bogie pivot center above the top of rail at a wagon tare of 20 t - 925 mm (+3/–5 mm) Specific bogie suspension for the axle load - up to 6.63 t (2.45 mm/t)) | over 6.63 ...
Tatravagónka a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 100, 120 km/h
Bogie mass: 4.3 t
... Wheel base - 1 800 Bogie centre pivot height at wagon weight of 20 t - 925 +3/-5 mm Lateral clearance size of axlebox-axleguard - 2 x 10 mm Specific bogie suspension for the axle load axle load up ...
Tatravagónka a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 100, 120 km/h
Bogie mass: 4.2 t
... Gauge - 1 435 mm Bogie centre pivot height at wagon weight of 20 t - 925 +3/-5 mm Lateral clearance size of axlebox-axleguard - 2 x 10 mm Specific bogie suspension for the axle load axle load up to ...
Tatravagónka a.s.
Load capacity (tons/axle): 22.5 t
Maximum supported speed: 100, 120 km/h
Wheelbase: 1,800 mm
... Gauge - 1 435 mm Bogie centre pivot height at wagon weight of 20 t - 925 +3/-5 mm Lateral clearance size of axlebox-axleguard - 2 x 10 mm Specific bogie suspension for the axle load axle load up to ...
Tatravagónka a.s.
Maximum supported speed: 120 km/h
Bogie mass: 4.9 t
Wheelbase: 1,800 mm
... Lateral clearance - ±10 mm Axle pin diameter - 130 mm Axle pin length - 190 mm Axle roller bearing - SKF, TIMKEN,... Bogie pivot with liner - áno Suspended side bearers - áno ...
Tatravagónka a.s.
Load capacity (tons/axle): 22.5, 25 t
Maximum supported speed: 120, 100 km/h
Bogie mass: 4.8 t
... of wheelset - ±10 mm Height of bogie pivot centre in the wagon with tare of 20 t - 925 mm Distance between side bearers - 850 mm Suspension stroke from empty condition ( wagon weight 20 t) to the loaded ...
Tatravagónka a.s.
Load capacity (tons/axle): 27 t
Maximum supported speed: 100 km/h
Bogie mass: 5.2 t
... Railway Wagon Bogie K6 Product details The bogie K6 incorporates spring support plates positioned amid the dual side frames. These plates interlink the left and right bearing springs while resting atop ...
Maximum supported speed: 140 km/h
Bogie mass: 7.2 t
Wheelbase: 2,560 mm
... Biaxial non-drive cradle-free type bogie mod. 68-7090-02/03 is designed to roll under diesel train cars on 1520 mm gauge railroads with a design speed of 140 km/h. The bogie is equipped: - Wheel sets with axle boxes ...
