USB hub USB-3.5-HUB

-Rugged, industrialized, four-port USB hub -High-speed USB 2.0 device, USB 3.0 and 1.1 compatible -Advanced EFT, Lightning, and ESD protection at ±20kV on all signal pins (air and contact) -Extended temperature (-40°C to +85°C) for industrial grade applications -Data transfer rates up to 480 Mbps -Supports bus powered and self powered modes -Three power input connectors (power jack, screw terminals, or 3.5″ drive Berg power connector) -LED status indicators for power and overcurrent fault conditions for each downstream port -USB/104 form-factor for OEM embedded applications -OEM version (board only) features PC/104 module size and mounting compatibility -Includes micro-fit embedded USB header connectors in parallel with all standard USB connectors -USB connectors feature industrial strength and high-retention design -Small (4″ x 4″ x 1″), low profile, steel enclosure -Designed, made, supported, and manufactured in the USA FACTORY OPTIONS -OEM (board only) version with PC/104 mounting holes and PCB footprint for added flexibility in embedded applications -Header connectors with jumper posts for panel mounted user status LED connection -3.5” front panel drive bay mounting provision -Wide Input power from 7VDC to 35VDC at the DC power jack or screw terminals The USB-104-HUB is a high performance, industrial grade, mountable solution for USB expansion. It is a high-speed USB 2.0 device, USB 3.0 and 1.1 compatible. Each of the four downstream ports are capable of high speed (480Mbps), full-speed (12Mbps), and low-speed (1.5Mbps) data transfers.
