Float level switch FROG

for waterCEpolypropylene

The FROG from ACOWA INSTRUMENTS is a standard float switch with a micro switch for either a Normally Open (NO) or a Normally Closed (NC) status signal. When it comes to efficient and reliable liquid level sensing, this float switch stands out as a top choice. Firstly, one of the key advantages of the FROG is its exceptional durability. Constructed using high-quality materials, this switch is built to withstand harsh environments and extreme conditions. Consequently, it ensures long-lasting performance and reduces the need for frequent replacements or repairs. FROG provides versatile use Moreover, FROG offers versatility in use. E.g. FROG is used as a high water level alarm in pump stations, low water level alarm in clean water tanks, water on floor alarm, as a controlling switch for pumps and many other functions. Also, this float switch is delivered in versions with a 10m or 20m fixed-mounted high-flexibility cable. A mounting bracket is included in both versions. Generel Info Contact system - Microswitch Voltage - Max 250V AC Max. rated current - 6A Resistive, 3A inductive Pressure range - 200kPA Cable length - 10m/20m Largest diameter - 99mm Length of floating element - 13mm, 19mm = 0,015% of FS at 25°C 16mm = Better than 2% Temperature coefficient of span - 140mm Tilting material - Polypropylene (PP) Cable material - PUR
