Control software IP XPORT

configurationproduction controlnetwork

IPXPORT lets you pass information from a serial port (COM port) of an ACRN machines to an Ethernet network. In a few moments, connect your devices to your network. You can take advantage of the features of the communication protocol of ACRN devices: Sending of the measured value on pulse, automatically or on interrogation Time stamp, unit, … Description In what situations should IP Xport be used? “Connected Plants” projects Centralization of production control data by connectiong control devices to the network. Archiving on a PC in production station Implementation of a SPC Plant software or other information system modules Includes: Cable Serial to Serial IP Xport Box 5V power supply with adaptater Connection guide Communication protocol guide for ACRN devices Configuration of the serial link Data bits - 5,6,7,8 Stop bits - 1,2 Check bit - None, Even, Odd, Space, Mark Baud rate - 600 bps~230.4Kbps Hardware compatibility: Torquemeters NBA, and NCA Terminal XA et XAm Vacuum box CTEX Tube seal tester ATS-X Aerosol pressure controler PA-X Ethernet Specifications Work mode - TCP Serveur, TCP, UDP Client, UDP Serveur, HTTPD Client Maximum client IP - 16 clients max in server mode DHCP supported - Yes Connexion control - Heartbeat functionnality Technical informations Connector A - COM Port (SERIAL) SUB-D female (for ma cable) 9 points Connecteur B - Ethernet Port RJ45 Dimensions - 71 x 60 x 25mm
