Bench-top torque meter TAM 4

for torque and angle measurementfor loosening torquedigital

The TAM 4 is a full motorized torque meter composed by a precision test bench with large choice of torque sensor, with a AFTI or XA-m digital display and accessories suited to customer needs. This device is appropriate to the laboratory / R&D world but also set up very easily at the edge of the production line thanks to his modest bulk and his robustness. This motorized torque tester permits to generate or control with a large accuracy a screwing and unscrewing torque deleting the human effect thanks to many gripping accessories and precise control of rotation speed. Benefits: -Control and visualization of the 4 following parameters: Rotation Speed Angle Acceleration To carry out the simplest to the most advanced tests: Control of unscrewing, Stop on torque, Screwing/unscrewing at a set angle, test of leakage of closing of plugs,… . Programming of the tests is done directly on the device You can save up to 40 programs The TAM torque meter integrates a powerful HMI, to perform operations and collections without the need for software and an external computer. Adaptable to all samples The TAM has many jaws and accessories allowing to test many different samples (smoothed caps, pumps, CRC type safety caps,…). Options Reinforced IP protection Specific jaws Delivered with: Mains cable A calibration certificate according to ISO6789/ COFRAC connection of standards A user manual A clamping system Technical informations Torque units - N.m / lbf.inch / N.cm / Kgf.cm Electrical and pneumatic suppy - 230 V / compressed air network from 0 to 10 bars Display - 7" backlit display
