Hand-held fume extractor UNI 2.2 E series

weldingactivated carbon filterdry filter

UNI 2.2 E is a mobile filtering unit with electrostatic filter, and it is studied for the extraction of dry and non-oily welding smokes in closed environments with medium concetrations of pollutants. UNI 2.2 E provides a filtration efficiency in class E11 >95%. Not suitable for use in potentially explosive areas. Powder-coated steel sheet metal, complete with pivoting castors and handles. A high-performance centrifugal fan is installed downstream of the filter section, in a special soundproof compartment. An AC motor with motor protection is controlled by a pc board placed in a clean chamber off the airflow circuit. The user-friendly digital control panel allows to monitor the main functions of the unit through a clogged filter alarm and other indicators. The unit is delivered with built- in wheels, ready to use. Filter section Filter section consisting of a series of metallic and acrylic filters, for a final filtration efficiency in class E11 >95%. The spark arrestor filter is standard included. A 10 kg active carbons post-filter is recommended in all cases of VOS/VOC, welding on stainless steel, zinc coated steel, chrome TIG etc.
