Industrial gas cylinder ARCAL™ Chrome

gasCO2cylindrical

DESCRIPTION
ARCAL™ Chrome, argon 2% CO₂ cylinder for welding: a shielding gas formulated for MAG welding of stainless steels. The mixture of argon with 2% CO₂ is designed to preserve corrosion resistance of stainless steels and to produce an attractive weld bead appearance. ARCAL™ Chrome has low levels of water and nitrogen impurities to reduce welding defects and minimise finishing operations. Suitable for manual, semi-automatic, automatic or robotic welding.

Applications

• Welding stainless steels in all positions and for general applications
• MAG brazing with CuSi and CuAl filler wires

Benefits provided by ARCAL™ Chrome

• Simplicity : optimal choice for MAG welding of stainless steels.
• Quality : preserves corrosion resistance properties of stainless steels (austenitic and ferritic).
• Performance : reduces finishing work thanks to very low spatter levels, improving productivity.

Carbon footprint reduction
ARCAL™ Chrome is produced and packaged in cylinders and frames in France using 100% renewable electricity (low-carbon production and packaging declared for certain sites).

Supply modes
Available in cylinders of various capacities and in frames (bundles of several cylinders) according to consumption volumes.

SMARTOP™
ARCAL™ Chrome argon 2% CO₂ cylinders can be fitted with the SMARTOP™ head: facilitates regulator connection, features an on/off lever and a pressure gauge for simplified handling and improved safety.

EXELTOP™
Optionally, cylinders can be equipped with an EXELTOP™ head integrating a regulator (double stage) for precise and stable flow, on/off lever and Quick Connect fitting for ready-to-use operation.

SAFETY & TRANSPORT
Hazards: contains gas under pressure; may explode if heated. Asphyxiant at high concentrations. Flammability range: non-flammable.
Transport: Official designation: Compressed gas cylinders. UN No.: 1956. ADR class: 2. Classification code: 1A.

Characteristics / technical specifications

• Reference: I2531
• Physical state: gaseous
• Relative density (gas): heavier than air
• Molecular weight: mixture
• Valve connection: ALTOP/EXELTOP: Quick Argon; SMARTOP: AFNOR C (21.7 x 1.814 SI - right-hand male); frame fitting: 38x2 (S)
• CAS No.: Ar: 7440-37-1; CO2: 124-38-9
• Single molecule: MIX
• Components (% vol. abs): Ar; CO2 2% ±0.5%
• Impurities (examples): H2O (5 bar) ≤ 40; O2 ≤ 50; N2 ≤ 200 (see technical data sheet for full details)
• Additional information: Product compliant with EN ISO 14175-M12-ArC-2 (welding application). Production/packaging available from renewable electricity sources (site-dependent).
• Colour: colourless
• Odour: odourless
