Industrial gas cylinder ARCAL™ He20µC

CO2He

Description
ARCAL™ by Air Liquide — shielding gas formulated for arc welding applications. Designed for MIG welding with a mixture of 20% helium and trace CO2 in argon, compliant with EN ISO 14175-Z-ArHeC-20/0,11 (welding application).

Applications

• Pulsed MIG welding of nickel alloys
• Pulsed MIG welding of materials sensitive to hydrogen-induced cracking
• Hardfacing / overlay welding

Safety and transport
Risks: Asphyxiation at high concentrations
Flammability range: Non-flammable
Official designation: Compressed gas cylinders
UN number: 1956
ADR class: 2
Classification code: 1A

Documents available

• Product data sheet (PDF)
• Material safety data sheet

Technical characteristics / specifications

• Reference: I2598L50S2A001
• Variation name: ARCAL He20 µC Bottle Smartop 50L 200 bar
• Pressure: 200 bar
• Package type and size: 50L
• Cap: SMARTOP
• Capacity: 10.2 m³
• Physical state: Gaseous
• Relative density (gas): Heavier than air
• Connection valve: AFNOR C (21,7 x 1,814 SI - right male)
• Mixture type: MIX
• Components (Vol. % / abs): Ar; CO2 1100 ppm ± 200 ppm; He 20% ± 2%
• Impurities: H2O (5 bar) ≤ 40 ppm; O2 ≤ 20 ppm; N2 ≤ 80 ppm
• Additional information: Product compliant with EN ISO 14175-Z-ArHeC-20/0,11 (welding application)
• Color: Colorless
• Odor: Odorless
