Induction drum heater BR-01

high-temperaturefor barrelsindustrial

Description
The AMARC induction base heater BR-01 is designed to heat 200 L steel drums and smaller containers and their contents. The top plate temperature is adjustable from 0°C to 120°C via an integrated thermostat. Diameter: 550 mm; Height: 80 mm. Price indicated on page: € 850 (ready in stock).

Usage / Compatibility

• Designed to heat 200 L steel drums and smaller containers.
• Can be used alone or in combination with heating jackets, side drum heaters or single drum heaters.

Technical data

• Power: 900 W
• Power supply: 230 V
• Current: 3.9 A
• Maximum temperature: 120°C
• Regulation (thermostat): 0°C - 120°C
• Protection: IP 44
• Diameter: 550 mm
• Height: 80 mm
• Weight: 15 kg
• Material: carbon steel
• Cable length: 3 m

Specifications

• Power: 900 W
• Supply: 230 V
• Current: 3.9 A
• Max temperature: 120°C
• Thermostat range: 0°C - 120°C
• Ingress protection: IP 44
• Diameter: 550 mm
• Height: 80 mm
• Weight: 15 kg
• Material: carbon steel
• Cable: 3 m
