Clean agent fire extinguishing system SAPPHIRE PLUS 70

Product description
SAPPHIRE PLUS uses the time‑proven technology of traditional SAPPHIRE systems while providing additional design benefits through increased operating pressure. The system is intended for total‑flooding fire protection using an environment‑friendly gaseous clean agent.

Features

• Temperature range: -18 to 65°C (0 to 149°F)
• Support for selector valves for multi‑hazard protection
• Extended pipe runs capability
• Designed for total flooding of hazard areas

Benefits

• Higher fill densities reduce number of containers and system footprint
• Lower installation cost and reduced service time
• Containers can be located farther from the protected space
• Ability to use selector valves to protect multiple hazards from a single container bank
• Protects personnel, the environment and high‑value assets
• Minimizes operational downtime through early fire detection and fast agent delivery

Technical specifications

• System name: SAPPHIRE PLUS
• System pressure: 70 Bar
• Agent type: environment‑friendly gaseous clean agent (clean agent fire suppression)
• Application: total flooding of hazard areas
• Temperature range: -18 to 65°C (0 to 149°F)
• Supports selector valves for multi‑hazard protection
• Supports extended pipe runs
• Design benefits: higher fill densities to reduce container count; ability to place containers farther from protected space
