Vertical lift gate

manualautomaticremote-controlled

Product overview
Automatic Traffic Dock Gate is the motorized version of the Traffic Dock Gate. This flexible, impact-resistant gate improves safety and traffic control in loading dock areas, gates, crossings and other zones where vehicle access needs temporary restriction. Unlike the manual model, it lifts and lowers automatically and supports multiple control integrations.

LED and signalling
The gate is fitted with LED indicators to show status (open/closed) and can optionally include high-intensity LED lighting to illuminate trailer interiors at the dock.

Main features

• Automatic opening and closing
• Access blocking for vehicle control
• Gate-status signalling with LED lights
• Automatic stop on detection of a person or vehicle during closing
• Impact-resistant design for collisions with forklifts

Control methods

• Remote control
• Access card system
• RFID
• Motion or laser sensors
• UWB (Ultra-Wideband)
• AI cameras detecting vehicles, pedestrians or selected traffic situations
• Manual push button
• Integration with client automation, wheel restraint systems or other dock equipment

Awards and certification
The product received the Gold Medal of the MTP Group (SAWO Fair) for innovation. It is TÜV certified and subject to annual production inspections; durability tests are carried out under TÜV Rheinland supervision.

Technical specifications

• Color options: yellow and black; base section optionally stainless or galvanized steel
• Material: polymer
• Width: 2000 mm – 4500 mm
• Height: 1100 mm
• Application: protection of gates, docks and loading ramps
• Internal fixing: M30 anchors
• External fixing: M16 anchors
• TÜV Certified
