Analog I/O module AI-08HL

CANopenModbus RTU8 analog inputs

Product overview
Analog input I/O module AI-08HL with 8 high-level analog inputs; supports CANopen and Modbus RTU networks and mounts on DIN rail.

Key features

• 8 high-level analog inputs
• Voltage: 0 … 10 V
• Current: 0 … 20 mA, 4 … 20 mA
• Interfaces: CANopen, Modbus RTU
• DIN-rail mounting; Power supply: 24 Vdc
• Operable in fast or enhanced mode via software commands

Additional information (table)
Dimensions: Single Module 76 x 110 mm
Power supply: 24 Vdc
Special functions: Accuracy 0.1%, Fast acquisition
Input channels: 8
Resolution: 16 bit
Protocol: CANopen, Modbus RTU
Certifications: CE, UL (listed)

Characteristics / technical specifications

• Model: AI-08HL
• Type: Analog I/O input module
• Inputs: 8 high-level analog inputs (voltage and current)
• Voltage input range: 0 … 10 V
• Current input ranges: 0 … 20 mA and 4 … 20 mA
• Resolution: 16 bit
• Operating modes: fast and enhanced (configurable via software)
• Interfaces: CANopen, Modbus RTU
• Power supply: 24 Vdc
• Mounting: DIN-rail
• Dimensions: Single Module 76 x 110 mm
• Special functions: Accuracy 0.1%, Fast acquisition
• Certifications: CE, UL (listed)
