Cartridge dust collector MP-EX

pulse-jet backflowcompactself-cleaning

Product Description This medium negative pressure explosion-proof dust collector is specifically designed for flammable and explosive dust applications. It features explosion-proof components including thickened steel plate construction, an explosion-proof VFD fan, anti-static filter cartridges, explosion-proof sensors, an explosion-proof electrical enclosure, and a rupture disc to safely handle flammable and explosive dust, ensuring safe production! Dust Collector Purification Principle Under the negative pressure generated by the fan, dust-laden air enters the filter cartridge chamber through the inlet pipe. Large, heavy particles settle into the dust collection hopper, while fine dust is retained on the outer surface of the filter cartridges as the airflow passes through. Clean air then flows into the clean chamber and is finally discharged through the outlet by the fan. When the pressure differential across the filter cartridges reaches the preset value, the pulse solenoid valve activates, performing instantaneous pulse-jet cleaning on the cartridges without machine shutdown. After cleaning, the pressure differential decreases and the dust collector returns to normal operation. Product Features - Medium negative pressure explosion-proof dust collection equipment specifically designed for flammable and explosive dust applications. - Equipped with an explosion vent for automatic pressure release and an independent explosion-proof electrical enclosure to ensure safe production. - Pulse automatic control system cleans filter cartridges based on differential pressure or timer, performing online reverse pulse cleaning to reduce downtime and maintenance frequency. - Features temperature monitoring with automatic alarm and shutdown in case of abnormalities to minimize risks. - End cap locking mechanism ensures excellent sealing and allows for quick assembly/disassembly, facilitating convenient filter cartridge replacement. - Horizontally positioned filter cartridges provide a large filtration area, reducing filter replacement frequency. - Ergonomic design for user-friendly operation. - Compact structural design with a small footprint for easy indoor placement, saving shipping costs and space. - Superior performance with high-end configuration and strong applicability. - Equipped with casters for easy mobility and leveling. Main Components - Three-color Indicator Light - Air Outlet - Control Panel - Wind turbine silos - Dust Hopper - Filter Cartridge Silo - Air Inlet - Dust Explosion-proof Fan - Explosion-proof Pulse Valve - Explosion-proof Sensor - Anti-static Filter Cartridge - Anti-static Surface Paint - Bursting Disc - Explosion-proof Dust Collector Integrated with Production Line Caractéristiques / Spécifications techniques - Explosion-proof design for hazardous dust environments - Thickened steel plate construction - Explosion-proof VFD fan - Anti-static filter cartridges - Explosion-proof sensors and electrical enclosure - Rupture disc for pressure relief - Pulse-jet cleaning system - Temperature monitoring and automatic alarm/shutdown - End cap locking mechanism for easy maintenance - Horizontal filter cartridge layout - Compact and ergonomic design - Equipped with casters for mobility
