Lever-operated hydraulic directional control valve 990100120

spool4/3-waystandard

Hand distributor valve 1000bar:for any hydraulic application Our hand distributor valve is standard on the UPM1000 model pump of the UP Series but it can be also applied – as an optional – to the UPC1000 model pump with Cetop3 flanged connections and to any other hydraulic application where a flow directional exchange is required in the system. Hand distributor valve 1000bar: main features Body and valve parts entirely in AVP Manual operation throughwith an ergonomic lever Lever in galvanized steel 4-way / 3-position valve (A-T-B) Open center Compatibility with single and double acting applications O-Ring seals in NBR 90SH Different flow configurations Materials resistant to stress even in harsh working conditions Anti-corrosion treatments for long durability over time Additional features of this valve: – Mechanically unlocked (3-position lever: neutral to discharge P-T, right and left for flow direction) – Hydraulically: – with open center (standard) = neutral position to discharge (P-T) – with closed center = neutral position under pressure (P) – hydraulic seal through the bushings on the 4 ways – Hand valve with almost zero pressure loss (zero leaking)
