Cylindrical distance sensor CE30-C
LIDARruggedweather-resistant

cylindrical distance sensor
cylindrical distance sensor
cylindrical distance sensor
Add to favorites
Compare this product


Characteristics

Configuration
cylindrical
Technology
LIDAR
Protection level
rugged, weather-resistant
Other characteristics
high-precision, non-contact, small, high-sensitivity, for automation, for agricultural machinery, for military applications, for mining equipment
Range

Min.: 0 m
(0'00" )

Max.: 4 m
(13'01" )

Description

Benewake launched CE30, a solid-state LiDAR with large FOV. It could simultaneously output grey and depth information within 132° horizontal FOV and 9° vertical FOV. Meanwhile no mechanical rotating component brings higher reliability and stability. Operating Range 0.1-4m Frame Rate 20fps Weight 219g Pixel Resolution 320*24 FOV 132°*9° Communication Interface TCP Product Features: 1.INTEGRATED METAL SURFACE, IP65 ENCLOSURE RATING · Mass Production · Large FOV · Wide Detection Range for Obstacle Avoidance · Cost Effective · 3D Scanning with Point-Cloud Data · Global Application 2.It could simultaneously output grey and depth information within 132° horizontal FOV and 9° vertical FOV 3.ANTI-CROSSTALK METHOD Integrated multi-machine interference determination and obstacle-avoidance algorithm to reduce the possibility of crosstalk 4.SOLID STATE FOR HIGH STABILITY AND RELIABILITY Solid-state design, no mechanical rotating component, great service life, high stability and reliability; small size, easy to integrate compact structural design, embedded in the robot 5.TWO MODES, MORE FLEXIBLE Two modes are available: Point Cloud Mode focuses on 3D depth information Obstacle Avoidance Mode further processesthe point-cloud data to output the positionof the nearest obstacle Application: Industrial robot, detection of abnormal item, Industrial robot, etc.
