Protection panel AABB
Add to favorites
Compare this product
Description
Product overview
The QMT AABB electrical panel is designed for transformer protection in 15–20 kV distribution networks. It integrates an SF6-insulated disconnect switch and a vacuum circuit breaker, with cable entry from the top and cable exit from the bottom. The unit includes a minimum voltage release for reliable protection coordination.
Key features
Applications
Technical specifications
The QMT AABB electrical panel is designed for transformer protection in 15–20 kV distribution networks. It integrates an SF6-insulated disconnect switch and a vacuum circuit breaker, with cable entry from the top and cable exit from the bottom. The unit includes a minimum voltage release for reliable protection coordination.
Key features
- SF6-insulated disconnect switch
- Vacuum circuit breaker
- Cable entry from the top, cable exit from the bottom
- Minimum voltage release (undervoltage protection)
- Designed for 15–20 kV distribution applications
Applications
- Protection of distribution transformers in industrial substations
- Secondary substations for utilities and commercial sites
- Switchgear cells requiring compact top-entry cable routing
Technical specifications
- Product code: AABB
- Brand: BTicino
- Rated voltage: 15-20 kV
- Height: 1.95 m
- Width: 750 mm
- Depth: 840 mm
- Series: QMT
