Orifice plate CLIF MOCK 5030

orifice plate
orifice plate
Add to favorites
Compare this product


Description

The CLIF MOCK Model 5030 single-chamber orifice fitting reduces the time and cost of inspecting and changing orifice plates, and helps ensure that the bore is properly centred in the meter tube. The single-chamber design makes installing and removing the orifice plate quick and easy by combining the orifice carrier and sealing bar in one assembly. By removing four bolts and a clamping bar, the user can pull the assembly from the fitting, replace the orifice plate and reinsert the assembly into the fitting in a matter of minutes. Additionally, with no flange bolts to remove and no flanges to spread, the risk of fluid loss from the pipeline is eliminated. Specifications Quick and easy access to orifice plates No risk of fluid loss from pipeline Compatible with standard seal rings and orifice plates Zinc-chromate plated clamping for corrosion resistance Fitting models available for Schedule 40 and Schedule 80 piping 600 lb ANSI rating, 1480 psi maximum working pressure
