Electric forklift EP series

ride-onindooroutdoor

Overview
Electric counterbalance forklifts EP16-35Q(L) are designed for light to medium duty indoor and outdoor material handling. The range covers 1.6 to 3.5 tonnes and offers flexible configurations to match common warehouse and site requirements.

Lower cost of ownership

• Li‑ion batteries deliver long service life, high energy efficiency and runtime with fast onboard charging and no need for battery swaps or water maintenance.
• Accessible service points and modular components reduce downtime and maintenance costs.
• Durable construction and effective sealing protect key components and minimise repair frequency.
• Front and rear super-elastic tyres extend service life and reduce vibration-related wear on components.
• Non‑marking tyre option lowers floor cleaning needs in sensitive environments.
• Cabin-ready overhead guard simplifies and reduces the cost of cabin installation.
• Cold-store modification (down to -18°C) preserves performance in low-temperature applications.

Productivity

• Li‑ion technology supports fast opportunity charging and onboard charging to keep trucks operational without battery exchanges.
• Super-elastic tyres maintain reliable traction and stability on uneven floors.
• Integrated (plug-in) and external charger options provide flexibility between convenience and faster charging needs.
• Choice of simplex and triplex masts to match different lift-height requirements.
• Standard hook-on side shift speeds up pallet placement and positioning.
• Optional fork positioner (including side shift) increases handling versatility for varied loads.
• Optional increased travel and lift speeds improve throughput where required.

Safety

• Intuitive controls, including conventional hydraulic levers, reduce operator training time.
• Optional fingertip controls for hydraulics and direction selection provide precise, low-effort operation.
• Seat suspension and optional luxury seat reduce vibration and improve operator ergonomics.
• Spacious operator compartment improves comfort and visibility.
• Glass roof option (or PVC roof on 3-wheel models) enhances upward visibility and protection.
• Optional front window with wiper maintains visibility in adverse conditions.
• Complete weatherproof cabin option is available for wet or cold environments.
• Road light kit, rear blue spot and strobe light options increase on-site and road visibility.
• Reverse warning buzzer and parabolic rear-view mirror improve safety during manoeuvres.
• Li‑ion battery chemistry eliminates risk of hazardous gas or acid leaks associated with some battery types.

Specifications (selected models)
Model | Capacity (kg) | Load Centre (mm) | Engine
EP16Q | 1600 | 500 | Electric
EP20Q | 2000 | 500 | Electric
EP25Q | 2500 | 500 | Electric
EP30Q | 3000 | 500 | Electric
EP35Q | 3500 | 500 | Electric
EP35QL | 3500 | 600 | Electric

Technical characteristics

• Commercial designation: EP16-35Q(L).
• Capacity range: 1.6–3.5 tonnes (1600–3500 kg).
• Standard load centre: 500 mm (EP35QL: 600 mm).
• Powertrain: electric, with Li‑ion battery options available.
• Battery/charging: onboard fast/opportunity charging or external charger options.
• Tyres: front and rear super-elastic tyres standard; non‑marking option available.
• Masts: simplex and triplex mast options for varied lift heights.
• Hydraulics: conventional hydraulic levers standard; optional fingertip controls.
• Material-handling options: hook-on side shift standard; optional fork positioner (including side shift).
• Environmental options: cold-store modification to -18°C; weatherproof cabin.
• Safety/equipment options: glass roof or PVC roof (3-wheel), front window with wiper, road light kit, rear blue spot, strobe light, reverse buzzer, parabolic mirror.
• Design focus: low total cost of ownership, easy servicing and protection against water-related damage.
