Electric pallet truck NPP20Q2L

lithium battery-poweredsteelfor warehouse

Overview
Carry heavy loads at low cost with the 2.0 tonne pedestrian power pallet truck NPP20Q2L. For light and medium warehouse duties, including transport of loads up to 2.0 tonnes, this pedestrian power pallet truck delivers reliable performance, easy manoeuvring and low operating costs.

Lower cost of ownership

• Robust steel chassis frame for long service life and reduced maintenance requirements.
• AC drive motor for extended durability and low upkeep.
• Optional Li‑ion battery provides long life, high efficiency and no water top-ups.
• External diagnostics port for fast plug-in troubleshooting and programming to reduce downtime.
• Quick-release service cover for easy access and faster maintenance.
• PIN code access and keyless start prevent unauthorised use and streamline operations.

Productivity

• Powerful drive delivers high performance and strong gradeability to overcome obstacles.
• Compact, stable design ensures manoeuvrability and safe operation in confined spaces.
• Optional automatic cornering speed reduction improves stability when turning.
• Li‑ion technology enables continuous operation with opportunity charging during short breaks.
• Advanced Battery Management System (BMS) optimises power, runtime and battery lifetime.

Safety

• Ergonomic spring-loaded long tiller arm for comfortable grip and low-effort control.
• Multifunctional tiller head places controls within easy reach for one-handed operation.
• Turtle/creep speed mode allows safe manoeuvring with the tiller vertical in narrow areas.
• Li‑ion battery chemistry reduces risks associated with hazardous gas or acid leaks.
• Load backrest option enhances pallet and load stability.

Technical specifications

• Model: NPP20Q2L
• Capacity: 2000 kg (2.0 tonnes)
• Load centre: 600 mm
• Drive: Electric (AC drive motor)
• Power source: Li‑ion battery option (advanced BMS)
• Construction: Steel chassis frame
• Service features: external diagnostics port, quick-release service cover
• Security: PIN code access, keyless start
• Controls: ergonomic spring-loaded long tiller arm, multifunctional tiller head, turtle/creep speed
• Optional: automatic cornering speed reduction, load backrest
