Optical data cable CX2-TR3FL/0.4-5
Add to favorites
Compare this product
Characteristics
- Type
- data
- Temperature
Min.: -40 °C
(-40 °F)Max.: 75 °C
(167 °F)
Description
Product series
Product overview
Key parameters
Mechanical/electrical parameters
Operating environment
Technical specifications
- Series: CX2 series fiber optic cable
- Model: CX2-TR3FL/0.4-5
Product overview
- Product type: Standard
- Construction: Needle-shaped
- Detection principle: Through-beam
- Connection: Fiber optic connector
Key parameters
- Detection distance: 0-35 mm
- Outer diameter: Ø3 mm
- Cable length: 2 m
- Light emission: Linear
- Minimum detectable object: Ø0.03 mm
- Accessories: Nut, washer
- Material: Metal
Mechanical/electrical parameters
- Connection: Fiber optic connector
- Cable bending radius: R10 mm
Operating environment
- Operating temperature: -40 °C to 75 °C
Technical specifications
- Product type: Standard
- Detection distance: 0-35 mm
- Construction: Needle-shaped
- Detection principle: Through-beam
- Outer diameter: Ø3 mm
- Cable length: 2 m
- Light emission: Linear
- Minimum detectable object: Ø0.03 mm
- Accessories: Nut, washer
- Material: Metal
- Connection: Fiber optic connector
- Cable bending radius: R10 mm
- Operating temperature: -40 °C to 75 °C
