AC clamp ammeter C116

portablemeasurement

The C Series is a range of high-performance 1,000 A transformer clamps. The round jaw shape and the uniformly-distributed winding guarantee accuracy and minimum phase difference. It is equipped with an oscillating magnetic element adjustment system and a patented system for gradual assisted jaw opening. Its Ø 52 mm clamping capacity allows current measurements on most conductors on CAT III 600 V industrial and tertiary installations. The excellent performance in terms of phase difference and linearity of this clamp equipped with a µmetal core fulfil the requirements for wattmeter applications. Main features of the C116 model: - Output signal: alternating voltage - Output / input ratio: 1 mV / A AC - Output via isolated Ø 4 mm female sockets
