CNC gear-shaping machine DC 1000

Product overview
The COMUR DC 1000 gear shaping machine is engineered for producing large internal and external straight spur gears. CNC-controlled automatic cutter positioning reduces setup time and limits cutter stroke to the minimum required. Extended capacity and precise kinematic ranges enable machining of workpieces to the stated dimensions. The machine is suitable for small-to-medium batches and can be integrated with an anthropomorphic robot for larger autonomous production.

Key features

• Max. module: 12 mm
• Max. workpiece diameter (external gear): 1150 mm
• Max. shaping width (tooth length): 210 mm
• CNC-controlled automatic cutter positioning for rapid setup
• Compatible with robot integration for high-volume or autonomous production

Technical data

• Model: COMUR DC 1000
• Min./max. distance between cutter spindle C/L and worktable C/L: 75 / 765 mm
• Min./max. distance between cutter spindle face and worktable face (with standard riser block): 490 / 740 mm
• Spindle stroking speeds (hydro guide): 20–450 strokes/min
• Machine dimensions (L × W × H): 4220 × 1430 × 3015 mm (with antivibration mounts H = 70)
• Machine weight: 10000 kg

Applications

• Production of internal and external straight spur gears
• Small-to-medium series manufacturing
• Automated high-volume production when coupled with anthropomorphic robots
