DIN rail mount temperature transmitter DT1012 series

Pt100Pt1000Pt500

•Pt100 / Pt1000 sensors or resistance / potentiometer •can be connected to the input •2 / 3 / 4 wire measurement •-200 – +800 °C / 0-4000 ohm max. measurement ranges •0-20 mA / 4-20 mA current and •0-10 V / 2-10 V voltage output ranges •3 way isolation (input / output / power supply) •High precision measurement •Easy configuration via USB port •24 VDC or 230 V AC/DC supply voltage •DIN rail housing, width: 12.5 mm PT100 / Pt1000 temperature sensors or linear resistance / potentiometer can be connected to the input of the DT1012… Temperature / resistance / potentiometer transmitters. The transmitter feature complete 3-way isolation: the input the output and the power supply circuits are isolated of each other using state-of-the-art planar transformer design. The transmitter has two outputs *: • 0 – 20 mA / 4 – 20 mA current, or • 0 – 5 V / 0 – 10 V / 2 – 10 V voltage * only one output can be used at the same time In the case of a Pt 100 / Pt 1000 temperature sensor, the output signal is proportional to the measured temperature, in the case of resistance to the measured resistance, in the case of a potentiometer, with the position of the potentiometer. Sensors can be connected to the input with 2 / 3 / 4 wires. In the case of a 3/4-wire connection, the connecting wires resistance does not affect the measurement. The transmitter can be configured via the USB port. The characteristics that can be specified are: input signal source, 2 / 3 / 4 wire measurement mode, measurement range, input signal averaging, output selection, output signal range, etc.
