Robotized screwing and assembly system ARG

for screw assemblyelectricprogrammable

Overview
ARG is a 3D vision system for robot guidance, built to provide alignment recovery and precise coordinate output for tightening and drilling operations on Stop & Go production lines. The solution combines a compact tool‑mounted 3D camera, a GPU-based processor running ARG software with AI models, and dedicated lighting to deliver fast and repeatable point localization where part position and orientation are non-repeatable.

Key benefits

• Address non-repeatable part placement: compensates positional and orientational variability on Stop & Go lines.
• Increase productivity: locates tightening/drilling points with 3D vision and supplies coordinates for auto-alignment to holes, bolts or screws.
• Reduce fixturing costs: removes the need for complex, inflexible mechanical fixtures.
• Operator-friendly: designed for straightforward installation, configuration and maintenance.

Main components (all-in-one kit)

• Camera: extra-compact 3D camera suitable for mounting on the end-of-arm tool to capture images close to the process area.
• Processor: GPU-based computer executing ARG software and trained AI models for 3D image analysis.
• Lighting device: dedicated lighting modules to ensure stable acquisitions even in very low ambient light.
• Software: HMI for operator ownership and optional low-code tools for advanced configurations.

Application cases

• Part orientation: detects features on randomly presented assemblies (e.g. seat backs) and guides the tool to the correct positions.
• Global assembly positioning: locates features on vehicles or sub-assemblies when conveyor stops are not precisely repeatable.
• Batch detection: tens of holes or features detected in a single acquisition to speed multi-point tightening/drilling.

Video summary
ARG product video demonstrates image acquisition, AI-based feature detection and coordinate delivery for tightening and drilling points in under one second in typical configurations.

Key facts

• 3D vision with high-precision depth sensing (VCSEL-based technologies as applicable).
• Batch detection capability: multiple holes/features per single image acquisition.
• Processing and coordinate output in under 1 second for typical use cases.
• Compatible with industrial robots and cobots; camera can be mounted on tool or in cell.

Technical specifications

• System type: 3D vision system for robot guidance (tightening and drilling).
• Primary components: tool-mounted compact 3D camera, GPU-based processor, lighting device, ARG software with HMI and optional low-code environment.
• Imaging technology: VCSEL / structured-light options for high-precision depth detection.
• AI analysis: trained models to detect holes, bolt heads, pre-mounted screws and other features.
• Batch detection: tens of features detected per acquisition within a defined ROI.
• Typical latency: end-to-end processing and coordinate delivery < 1 second (typical configuration).
• Integration: camera placement on tool or in cell, calibration to robot coordinate system, supports Stop & Go lines.
• Use cases: non-repeatable feature localization, part orientation, global assembly positioning, tightening and drilling guidance.
• Operator controls: HMI for standard use; low-code for advanced setups.
