Compact 127.0mm x 101.6mm, header type
• LCD panel support: Up to 2560x1600, 10-Bit
• Panel connectivity: LVDS
• Inputs - headers: HDMI, DP, VGA,
• Inputs - micro-BNC: 3G-SDI
• Programmable hot-keys
• Picture-in-Picture (PiP), Picture-by-Picture
• IR remote & RS-232 control
The HX-2560-SDI is a compact, advanced LCD controller for video signals up to 2560x1600 and LCD panel resolutions up to 2560x1600 with LVDS panel connection. Header type connectors are provided for HDMI, Displayport, and VGA inputs together with micro-BNC connectors for 3G-SDI connection. The very extensive feature set combined with the suitability for harsher environments due to wider operating temperature range and a conformal coating ensures suitability for many display applications. The HX-2560-SDI is supported by a wide selection of panel connection cables and other accessories together with system development documentation including 3D drawings.
