Omnidirectional inclinometer INC-E725

RS-485voltage output4-20 mA

The INC E725 inclinometer is the ideal solution to measure and / or verify a precise inclination of the steel cables of overhead cranes, gantries, elevators or load movement equipment such as rockers, stackers, loaders among others, preventing and avoiding possible accidents caused by improper operations. The INC-100 inclinometer differs from conventional models in that, instead of detecting the X / Y angles (horizontal and vertical) separately, it does so in any area of ​​360º. Being a three-axis inclinometer, it makes it possible to work in all positions. Electronics Technical Data: * Output of three programmable relays: (lim1 / lim2 / lim3) * Output type: switchable relay * Maximum voltage: 250V * Maximum current: 6 A * Input signal: 4 to 20 mA * Working temperature: -10 to 50ºC * Buttons: 3 for programming (S1, S2, S3) * Display: 8-digit alphanumeric LCD * Power supply: 90 to 240Vac, 12 Vdc, 24Vdc, 48cc * Power consumption: <5w * Full scale: 180º * Resolution: 0.5ºC * Dimensions: 90x72x70mm Sensor Technical Data: * Power supply: 90 to 240V * Output signal: 4 / 20mA (0-180º) * Operating Temperature: -10 to 60ºC * Cable 5 meters * Dimensions: 76x35x20 mm
