3-axis CNC milling center NHX 5500horizontalhigh-precisionhigh-speed
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3-axis
- Spindle orientation
- horizontal
- Other characteristics
- high-precision, high-speed, high-rigidity
- X travel
800 mm
(31 in)- Y travel
800 mm
(31 in)- Z travel
880 mm
(35 in)- Workpiece max height
1,100 mm
(43 in)- Work feed X-axis
60,000 mm/min
(39 in/s)- Work feed Y-axis
60,000 mm/min
(39 in/s)- Work feed Z-axis
60,000 mm/min
(39 in/s)- Table load capacity
1,000 kg
(2,205 lb)
Description
High speed
Rapid traverse rate X-, Y- and Z-axes: 60 m/min (2,362.2 ipm)
Max. acceleration: X-, Y- and Z-axes: 0.73 / 0.80 / 0.93 G {7.2 / 7.8 / 9.1 m/s2 (23.6 / 25.6 / 29.9 ft/s2)}
Cutting feedrate X-, Y- and Z-axes: 60 m/min (2,362.2 ipm)
High rigidity
Thick, high-rigidity bed
The 3-point support structure ensures a stable machine installation
Machining with shorter tools
High-precision equipment
High-resolution direct scale feedback
Draw-back function for through-spindle coolant
