LPG forklift G series
ride-onhandlinghigh-speed

LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling / high-speed
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling / high-speed
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling / high-speed - image - 2
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling / high-speed - image - 3
Add to favorites
Compare this product

Characteristics

Motor type
LPG
Operator
ride-on
Applications
handling
Other characteristics
high-speed
Carrying capacity

2,500 kg, 3,000 kg, 3,300 kg, 3,500 kg
(5,511.6 lb, 6,613.9 lb, 7,275.3 lb, 7,716.2 lb)

Lifting height

Min.: 3,000 mm
(118.11 in)

Max.: 7,060 mm
(277.95 in)

Overall width

1,290 mm
(50.8 in)

Overall length

3,660 mm, 3,715 mm, 3,780 mm, 3,800 mm
(144.1 in, 146.3 in, 148.8 in, 149.6 in)

Load center distance

500 mm
(19.7 in)

Weight without load

3,930 kg, 4,400 kg, 4,600 kg, 4,720 kg
(8,664.2 lb, 9,700.3 lb, 10,141.3 lb, 10,405.8 lb)

Axle loading with maximum load front

5,560 kg, 6,480 kg, 6,940 kg, 7,220 kg
(12,257.7 lb, 14,286 lb, 15,300.1 lb, 15,917.4 lb)

Axle loading with maximum load rear

870 kg, 920 kg, 960 kg, 1,000 kg
(1,918 lb, 2,028.3 lb, 2,116.4 lb, 2,204.6 lb)

Axle loading without load front

1,670 kg, 1,730 kg, 1,795 kg
(3,681.7 lb, 3,814 lb, 3,957.3 lb)

Axle loading without load rear

2,200 kg, 2,605 kg, 2,870 kg, 3,050 kg
(4,850.2 lb, 5,743 lb, 6,327.3 lb, 6,724.1 lb)

Track width front

965 mm, 980 mm
(38 in, 38.6 in)

Track width rear

980 mm
(38.6 in)

Height of mast when lowered

2,160 mm, 2,185 mm
(85 in, 86 in)

Free lift

145 mm, 150 mm
(5.7 in, 5.9 in)

Overall height with mast raised

4,250 mm
(167.3 in)

Height to top of overhead guard

2,183 mm
(85.9 in)

Seat height

1,185 mm
(46.7 in)

Length to fork face

2,630 mm, 2,730 mm, 2,755 mm
(103.5 in, 107.5 in, 108.5 in)

Fork carriage width

1,042 mm
(41 in)

Ground clearance under mast with load

105 mm, 130 mm
(4.1 in, 5.1 in)

Ground clearance at center of wheelbase with load

135 mm, 140 mm
(5.3 in, 5.5 in)

Turning circle radius

2,330 mm, 2,415 mm, 2,460 mm, 2,480 mm
(91.7 in, 95.1 in, 96.9 in, 97.6 in)

Travel speed

18.5 km/h
(11.5 mph)

Lifting speed

0.45 m/s, 0.48 m/s, 0.55 m/s, 0.63 m/s
(1.476 ft/s, 1.575 ft/s, 1.804 ft/s, 2.067 ft/s)

Lowering speed

0.45 m/s, 0.5 m/s
(1.476 ft/s, 1.64 ft/s)

Rated drawbar pull

1,770 N, 1,780 N, 1,830 N

Gradeability

23.5 %, 24.5 %, 29 %

Rated output

45.4 kW
(61.7 hp)

Cubic capacity

2,359 cm³
(79.8 US fl oz)

Maximum operating pressure

200 bar
(2,900.8 psi)

Oil flow

65 l/min
(17.2 us gal/min)

Noise level

78 dB

Description

Our NX Plus Series LPG forklifts offer excellent value with powerful performance. User safety is prioritized with seat-sensing technology, hydraulic mast interlock, and enhanced ergonomics that prevent unintended movements. High-speed lifting, wide mast visibility, and strong gradability enhance warehouse productivity. Features Ergonomics Anti-slip Step Plate The wider step plate prevents slipping and facilitates safer mounting/dismounting from the truck. Adjustable Steering Column The steering column offers a wide range of adjustable angles, allowing operators to have optimal posture for comfort and control. Integrated Lamp Switch The turn signal and headlamp switches are intuitively integrated. Spacious Legroom More legroom has been created by removing the tilt cylinder from the floor plate. The angle of the gas pedal and brake have been improved to reduce ankle fatigue. Productivity High Speed Lifting/Lowering The gear pump and mast regulator valve have been optimized to increase the lifting/lowering speed, boosting the effiency of your forklift. Wide Mast Visibility The neatly arranged hydraulic hoses and chains enhance wide front visibility. Powerful Gradeability The powerful engine, transmission, and auxiliary weight structure of the forklift allows it to easily navigate steep slopes. Powerful Engine The HMC G424I engine handles workloads under any condition, maintaining a consistent torque curve. It offers a balance of durability and low noise while complying with Euro Stage V regulations. Reliability Anti-Dust Design The bottom-sealed overhead guard prevents dust from entering the bottom side. Auxilary Weight
