LPG forklift G series
ride-onhandling

LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling - image - 2
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling - image - 3
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling - image - 4
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling - image - 5
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling - image - 6
LPG forklift - G series - Doosan Industrial Vehicles - ride-on / handling - image - 7
Add to favorites
Compare this product

Characteristics

Motor type
LPG
Operator
ride-on
Applications
handling
Carrying capacity

4,000 kg, 4,500 kg, 5,000 kg, 5,500 kg
(8,818.5 lb, 9,920.8 lb, 11,023.1 lb, 12,125.4 lb)

Lifting height

Max.: 6,050 mm
(238.19 in)

Min.: 2,750 mm
(108.27 in)

Overall width

1,370 mm, 1,455 mm
(53.9 in, 57.3 in)

Overall length

4,165 mm, 4,215 mm, 4,480 mm, 4,525 mm, 4,550 mm
(164 in, 165.9 in, 176.4 in, 178.1 in, 179.1 in)

Load center distance

600 mm
(23.6 in)

Weight without load

Max.: 7,390 kg
(16,292.2 lb)

Min.: 5,790 kg
(12,764.8 lb)

Axle loading with maximum load front

Max.: 11,370 kg
(25,066.6 lb)

Min.: 8,980 kg
(19,797.5 lb)

Axle loading with maximum load rear

1,075 kg, 1,200 kg, 1,250 kg, 1,520 kg
(2,370 lb, 2,645.5 lb, 2,755.8 lb, 3,351 lb)

Axle loading without load front

Max.: 2,890 kg
(6,371.4 lb)

Min.: 2,660 kg
(5,864.3 lb)

Axle loading without load rear

Max.: 4,590 kg
(10,119.2 lb)

Min.: 3,105 kg
(6,845.4 lb)

Track width front

1,138 mm, 1,153 mm
(44.8 in, 45.4 in)

Track width rear

1,115 mm
(43.9 in)

Height of mast when lowered

2,380 mm
(93.7 in)

Free lift

160 mm, 170 mm
(6.3 in, 6.7 in)

Overall height with mast raised

4,265 mm, 4,270 mm, 4,420 mm, 4,470 mm
(167.9 in, 168.1 in, 174 in, 176 in)

Height to top of overhead guard

2,225 mm
(87.6 in)

Seat height

1,248 mm, 1,255 mm
(49.1 in, 49.4 in)

Length to fork face

Max.: 3,350 mm
(131.9 in)

Min.: 3,115 mm
(122.6 in)

Fork carriage width

1,250 mm, 1,330 mm
(49.2 in, 52.4 in)

Ground clearance under mast with load

150 mm, 160 mm
(5.9 in, 6.3 in)

Ground clearance at center of wheelbase with load

205 mm
(8.1 in)

Turning circle radius

2,782 mm, 2,975 mm
(109.5 in, 117.1 in)

Travel speed

19.5 km/h, 20 km/h
(12.1 mph, 12.4 mph)

Lifting speed

0.47 m/s, 0.5 m/s, 0.54 m/s
(1.542 ft/s, 1.64 ft/s, 1.772 ft/s)

Lowering speed

0.45 m/s, 0.48 m/s, 0.49 m/s
(1.476 ft/s, 1.575 ft/s, 1.608 ft/s)

Rated drawbar pull

Max.: 34,740 N

Min.: 33,860 N

Gradeability

Max.: 73.4 %

Min.: 27.8 %

Maximum operating pressure

140 bar
(2,030.5 psi)

Oil flow

80 l/min
(21.1 us gal/min)

Description

The 7-Series LPG Forklift prioritizes safety, offering enhanced features such as an anti-slip step plate, panoramic mirror for visibility, and an operator sensing system that halts travel and mast lifting when the operator leaves the seat. Its fuel-efficient Kubota engine integrates and coordinates critical functions for optimal performance. Features Ergonomics Premium Seat The seat is designed with a low-profile mechanical suspension that significantly reduces vibrations. It helps the operator stay comfortable no matter how rough the day gets. Adjustable Steering Column The steering column offers a wide range of adjustable angles, allowing operators to have optimal posture for comfort and control. Tilt Cylinder Covers The tilt cylinders are neatly covered to avoid any obstruction. The cover also creates additional space on the floor of the operator compartment. Instrument Panel The easily readable, integrated instrument panel provides operators with a clear overview of the truck’s operation status, simply by navigating the instrument panel. Productivity LED Combination Lamps Brighter and longer lasting than traditional sealed beams or halogen lights. Mast Visibility The neatly arranged hydraulic hoses and chains enhance wide front visibility. Improved Fuel Consumption The addition of roller valve lifters reduces friction and enhances fuel efficiency. Fuel Efficient Engine The Kubota engine is powered by an ECU that integrates and coordinates essential functions such as the governor, variable ignition timing, air-fuel ratio control, and engine protection.
