Pressure data-logger EBI 12-TP422

temperaturewirelesswithout display

Validation logger for thermal testing of processes with steam sterilizers. The logger is characterized by its bendable metal probes. The very thin temperature sensors with a diameter of 1.5 mm at the sensor tip enable a very fast response time. Benefits: • bendable metal probe • high accuracy • Realtime data transmission • fast response time • sterilizable data logger Applications: • Validation logger for Measurement in the steam sterilizer, WD and endoscope washer Technical Data Weight aprox. 120 g Accuracy ±0,1 °C (0 °C ... +120 °C) ±0,05 °C (+120 °C ... +140 °C) ±0,1 °C (+140 °C ... +150 °C) ±15 mbar (1 mbar ... 50 mbar), ±10 mbar (50 mbar … 150 mbar), ±10 mbar (2.050 mbar … 2.250 mbar), ±10 mbar (3.000 mbar … 3.250 mbar), ± 15 mbar (3.250 mbar ... 3.500 mbar), ± 0,5 % FS (3.500 mbar ... 4.000 mbar) Dimensions ø 48 mm x 32 mm - Needle length 500 mm Certificate Factory Calibration: 0 °C, +60 °C and +134 °C 100 mbar and 3,100 mbar at +25 °C and 3,100 mbar at +134 °C Measured variables Temperature, pressure Intervall 250 ms ... 24 h Battery 3.6 V lithium battery exchangeable
