Hydraulic fitting TOF series

screw-insocketelbow

TEMPERATURE LIMITS: min. +5°C - max +85°C. Thread: ISO 228 PIPE CUTTING Provide a perpendicular Cut using appropriate toolings. PIPE CLEANING Remove the burrs from the pipe (inside & outside). ASSEMBLING INSTRUCTIONS Put the nut and the compression ring on the outside of the pipe and then insert the pipe into the fitting until it is totally against the bottom of socket, the o-ring must remain in the original position. Tight the nut by hand, using a spanner, and than screw it.
