DIN rail power supply ALE1225
AC/DCsingle-outputregulated

DIN rail power supply - ALE1225 - ELC construction électronique - AC/DC / single-output / regulated
DIN rail power supply - ALE1225 - ELC construction électronique - AC/DC / single-output / regulated
Add to favorites
Compare this product

Characteristics

Mounting / format
DIN rail
Type
AC/DC
Output
single-output, regulated, stabilized, adjustable
Technology
switching, PWM
Network
single-phase
Protection
with short-circuit protection, with overcurrent protection, with surge protection
Applications
for automation, for industrial applications, electronic equipment, for electrical networks, for telecom applications, for marine applications, for railway applications, for EMI/EMC, emergency battery, for access control, for distribution panels, for control boxes
Other characteristics
with power factor correction, low-noise level, RoHS compliant, redundant, isolated
Input voltage

230 V, 440 V

Min.: 190 V

Max.: 440 V

Output voltage

10 V, 12 V, 15 V

Min.: 10 V

Max.: 15 V

Current

20 A, 25 A

Min.: 0 A

Max.: 25 A

Power

300 W

Description

300W power supply (600*, 900*, 1200Watts*...) Ref : ALE2412 24 V / 12,5 A (Adj. 20 to 30V / 15A, beyond : 10 A) UNIVERSAL : 190 to 440V main input voltage PRECISE : output ripple < 3mV rms COMPLIANT : EN61000-3-2, built in actif power corrector (PFC) DIAGNOSTIS : Alarm by Relay with invert contact PRACTICAL : Output voltage adjustable from 10 to 15V *POWERFUL : to cumulate n+1(Parallel active mode) PROTECTED : against short-circuits EASY : Direct DIN rail mounting Spring terminal blocks 12 V, 25 A, 300 W, RoHS
